CLWDFV1163GP6S4
Free Guarantee for 1year
Free Technology Service for Life
S
ISO9000, CCC, TS16949, EPA
Euro 3
120HP
2t
Diesel
Manual
4x2
New
360
7 M
70
Double Row Cabin, One and Half Row Cabin, Single
16 - 28 M
Articulated Booms
CLW
Roro, Bulk, Container
China
8704230090
Product Description
ISUZ 600P 28M Articulated Booms Aerial Working Platform Truck
1.Competitive Advantage :Electro-hydraulic proportional control , stepless throttle
A . With a 2-section telescopic boom crane
B . Control box at both turret and platform
C . Limit switch and alarm
D . Emergency descent power
E . Safety interlock
F . Large outrigger span, outrigger can be operate individually
2. Feature :
We are a professional supplier of aerial working platform trucks in China , and we can provide our customers various configuration trucks with different prices .
1 . Emission standard : Euro 2 / 3 / 4 / 5
2 . Truck brand : Dongfeng , JMC , ISUZ , JAC , Foton , IVEC etc
3 . Cab : double-Row ( rated passengers : 6 ) , One&Half-Row ( rated passengers : 3 )
4 . Steering control : Left Hand Dive / Right Hand Drive
5 . Working height : 10m , 12m , 14m , 16m , 18m , 20m , 22m , 24m 28m.
6 . Boom type : Articulated Booms and Telescopic Booms
7 . Hydraulic lifting system : 360° rotation ;
8 . Arms ( outriggers ) No. : two , three , four or five arms ;
9. Legs : equip with H-mode hydraulic legs .
10 . The hydraulic operation system : set in the upper and lower end of the truck , equip with working platform & lifting hook .
11 . Platform : mounted at the boom end provide enough space for the working person to work eas
| Vehicle name | 28M ISUZ 600P Articulating Booms Aerial Working Platform Truck |
Chassis | |
| Cab | ISUZ 600P , double row cabin , A/C |
| Engine model | 4KH1-TCG40 / 88KW / 120HP /2999ml |
| Engine emission standard | Euro IV |
| Engine manufacture | ISUZ Co. Limited |
| Fuel type | Diesel |
| Tire | 7.00-16 |
| Wheelbase | 3360mm |
| Gear box | ISUZ MSB 5-speed |
Boom | |
| Boom type | Articulated Booms |
| Upper boom lifting angle | 70° |
| Lower boom lifting angle | 70° |
| Turn around angle | 360° |
Platform | |
| Max.Rated.Load | 200kg(2 persons) |
| Max.Working Height | 28M |
| Max Height off ground | 14.3M |
| Max. working range | 7M |
Outrigger | |
| Adjustment | Individual adjustment |
| type | H type |
HOOK | |
| Max. loading | 1000kg |
PRODUCT SHIPPING (RORO OR BULK SHIP)
RORO: The truck is driven to the ship inside directly and fixed well. It can protect the truck being rusty and broken during shipping.
BULK: The truck is lifted by crane then put on the vessel deck. This model is much cheaper.
CONTAINER: The truck is put into the container. This model is used for small model trucks
FAQ
1.You are factory or trading Company?
Yes, we are oversea sales department of Chengli automobile . And you are always welcomed to visit our factory.
2.Could your company modify the standard product depends on my request?
Yes. Our company is specialized in researching and designing various of special purpose vehicle and spare parts. We can provide any product according to your demand.
3. Could your company totally customize products for me?
We can provide the customized-designing product meeting with any of your demand.
4. Could you provide certification that we need?
We can provide various certifications associate with trailer and truck. Such as DOT, ADR, SASO and so on.
5. How long could we receive our goods?
It depends on the product that you have ordered. If the goods are prepared, we will deliver your goods as soon as possible.
6. How about the after-sale service?
We can provide you the technical support to guide you repaire your product. And we will also send original spare parts free of charge by air. If you have special need, we can let our engineer to help you in person
More details Plz Contact uS
CHENGLI SPECIAL AUTOMOBILE CO.,LTD
Overseas Sales Department :
Echo Wong ( manager)
Office Add: Overseas17# Building Room 6026 ,South Surb Chengli Automobile Industry Park,Suizhou City.
Factory Add.:South Surb Chenli Automobile Industry Park ,Suizhou City, Hubei Province ,China.
