JH-8 Prop Pulling Winch
on Line or Video
One Year
Electric Winch
DC
Fast
Weight Level
1T
1
Moving
Explosion-Proof
CE, ISO 9001
National Standards
80
0.12
280* 230
100
650
zhongmei
Wooden Case or Carton Case
JH-8 prop pulling winch
Shandong, China
Product Description
Introduction of JH-8 Explosion-Proof Lift Winches Ce/ Ma Certification Prop Pulling Winch
Prop-pulling hoist also called slow winch, used for the coal mine coal mining working face prop-pulling caving. Because of its low height and light in weight, especially suitable for thin coal seam and steep coal seam mining face, the mining face and a variety of recycled into floor or by waste rock pressure of buried metal pillar. With the improvement of mechanized degree, it is increasingly widely used in mechanization mining face, the installation of various equipment and spare parts, recycling traction.zmwm02
Parameter of JH-8 Explosion-Proof Lift Winches Ce/ Ma Certification Prop Pulling Winch
| Model Parameter | JH-5 | JH-8 | JH-14 | JH-20 | JH-30 | |
| Steel wire rope average static tension (KN) | 50 | 80 | 140 | 200 | 300 | |
| Steel wire rope (m/s) average speed | 0.17 | 0.12 | 0.115 | 0.118 | 0.13 | |
| Drum | diameter*width (mm) | 276* 372 | 280* 230 | 400* 317 | 430* 530 | 550*560 |
| rope capacity (m) | 80 | 100 | 130 | 170 | 220 | |
| Steel wire rope | diameter | 15.5 | 17 | 21.5 | 24.5 | 30 |
| construction | 6* 19 | 6* 19 | 6* 19 | 6* 19 | 6* 19 | |
| nominal extension strength (Mpa) | 1550 | 1550 | 1550 | 1550 | 1570 | |
| Explosion proof motor | Model | YBJ7.5-4 | YBK2-160M-6 | YBK2-200L1-6 | YBK2-200L2-6 | YBK2-280S-4 |
| Power (KW) | 7.5 | 7.5 | 18.5 | 22 | 45 | |
| Voltage (V) | 380/660 | 380/660 | 380/660 | 380/660 | 380/660 | |
| Rotate speed (r/min) | 1450 | 970 | 970 | 970 | 980 | |
| Overall size: L* W* H | 1450*512*515 | 1550*530*570 | 1955*680*815 | 2560*968*797 | 3300*1077*1034 | |
| Winch weight (including motor) | 620 | 650 | 1350 | 2600 | 4460 | |
Pictures of JH-8 Explosion-Proof Lift Winches Ce/ Ma Certification Prop Pulling Winch
