1.5T-Electric Forklift
Have
1 Year
Adjustable
Electric Forklift
DC Motor
≤1T
Electric
>500mm
3000~5000mm
New
1500kg
500
Hand Brake, Oil Brake
300 0W DC
Lighting Lights, Left and Right Turn Signals, Brak
Hydraulic Power Steering
Anti-Slope High Power Controller
60V
3000W Non-Full AC
Standard Steel Body
zhongmei
Wooden
3720*1200*2100
Shandong, China
Product Description
Introduction of Full AC System High Efficiency Small Motorized Pallet Material Handling Crane
• Full AC System
• OPS System
• Comfortable Operator Space
• Side-way Battery Change System
• Lower Energy Consumption and Energy Regeneration Function
• Easy-to-read operator display
• Front Dual AC Motor Traction System
• World Class Gear Box System
• Automatic Maintenance Alarm
* Zero-Emission, Zero-Pollution, Low-Level Vibration, Low-Level Vibration, Low Operation Cost, High Efficiency, High Quality, these are the reasons for you to choose Electric Forklift.
* The Energy Regeneration Function extend extra 15% working hours,which provide the possibility for your tough and long-time working condition.zmwm17
• OPS System
• Comfortable Operator Space
• Side-way Battery Change System
• Lower Energy Consumption and Energy Regeneration Function
• Easy-to-read operator display
• Front Dual AC Motor Traction System
• World Class Gear Box System
• Automatic Maintenance Alarm
* Zero-Emission, Zero-Pollution, Low-Level Vibration, Low-Level Vibration, Low Operation Cost, High Efficiency, High Quality, these are the reasons for you to choose Electric Forklift.
* The Energy Regeneration Function extend extra 15% working hours,which provide the possibility for your tough and long-time working condition.zmwm17
Parameter of Full AC System High Efficiency Small Motorized Pallet Material Handling Crane
| vehicle parameters | The body size, height and other configurations can be customized according to customer needs | ||
| Technical Parameters | Maximum Lifting Weight | 15 00kg | |
| long | 2 1 00 mm without forks | ||
| long | 3 1 70mm including fork | ||
| Width | 1200 mm | ||
| high | 2100 mm | ||
| Vehicle weight | 2 2 00kg | ||
| Lifting height | 3 meters | ||
| body material | Standard steel body | ||
| Electrical System | travel motor | 3000W non-full AC | |
| Voltage | 60V | ||
| vehicle power | pure electric | ||
| Battery | 60v5 lead-acid batteries | ||
| lights and signals | Lighting lamps, electric horns, etc. | ||
| Chassis system | front bridge | Full floating integrated heavy-duty front axle | |
| tire | Front wheel 650-10 ( solid tire) rear wheel 500-8 ( solid tire) | ||
| Steering axle | Heavy-duty forklift special rear axle | ||
| braking method | hand brake oil brake | ||
| other configuration | Lift cylinder | Reinforced sealed double oil cylinder | |
| Fork length | 1 220mm _ Forged Forks | ||
| hydraulic lift motor | 300 0w DC | ||
| Gantry material | C-shaped steel | ||
| Steering | hydraulic power steering | ||
| Turning radius | 90° turnable in situ | ||
| charging time | 6 hours | ||
| Continuous working time | 6-8 hours | ||
| climbing angle | 15° | ||
| Car accessories | Charger Awning Instruction Manual | ||
Photos of Full AC System High Efficiency Small Motorized Pallet Material Handling Crane
