The product has reasonable structure; beautiful appearance, economic and durable and also can match various types of tractors, it is divided into many kinds of types :single axle of two wheel trailer, double axles of four wheel trailer, hydraulic dump or no-hydraulic dump .it also can be made according client's requirements,the following parameters table is only for reference .
1.MODEL | 7CX-10 Trailer | 7CX-20 |
Carriage dimension(mm) | down 4300*2100*1400+300mm | 6400X2500X1800mm |
Overall dimension(mm) | 6000*2250*2650mm | 8250x2650x3315mm |
Rated load weight(kg/t) | 10000.00kgs /10T | 20000.00kgs/20T |
Tire | 4PCS 445/45R19.5 Radial tire | 4PCS 650/50R22.5 Radial tire |
Unload form | Hydraulic lift | manual back tipping |
Brake form | Air brake | brake by foot |
Quantity /40GP | 2PCS/40HQ | 2PCS/40HQ |
| Model | unit | 7C-3 | 7C-4 | 7C-5 | 7C-6 | 7C-7 | 7C-8 | 7C-9 | 7C-10 |
| Loading weight | kg | 3000 | 4000 | 5000 | 6000 | 7000 | 8000 | 9000 | 10000 |
| Box size | cm | 340*180*50 | 340*190*50 | 3600*190*50 | 380*200*50 | 400*200*50 | 430*200*50 | 470*200*50 | 520*200*50 |
| Tyre /Q'ty | 7.50-16/4 | 7.50-16/4 | 8.25-16/4 | 8.25-16/4 | 9.00-20/4 | 9.00-20/4 | 9.00-20/4 | 9.00-20/4 | |
| Total weight | kg | 1270 | 1350 | 1750 | 1870 | 1980 | 2200 | 2500 | 3100 |
| Brake | air pneumatic brake | ||||||||
| Matched power | hp | 30 | 40 | 50 | 60 | 70 | 80 | 80-100 | 90-120 |
| Linkage | Trailed | ||||||||
| The items selectable | M20*1.5 Tipping single action oil cylinder,oil connection in 1/2" thread,gas connection M20*1.5 | ||||||||
| Model | unit | 7C-3/7CX-3 | 7C-4/7CX-4 | 7C-5/7CX-5 |
| Loading weight | Kg | 3000 | 4000 | 5000 |
| Box size | Mm | 2600*1500*450 | 2800*1600*450 | 3000*1700*450 |
| Tyre /Q'ty | 10.00-75/2 | 10.00-75/2 | 8.25-16/2 | |
| Total weight | Kg | 820/980 | 890/1050 | 940/1140 |
| Brake | air pneumatic brake | |||
| Matched power | Hp | 30-40 | 40-50 | 50 |
| Linkage | Trailed | |||
| The items selectable | M20*1.5 Tipping single action oil cylinder,oil connection in 1/2" thread,gas connection M20*1.5 | |||
OTHER TYPE OF FARM TRAILER
Product range
we have five ranges of related product,including tider,water pump,generator,power sprayer and engines,(Inlude all kind of implement for tractor )
you never worry to gather different model for same container,we can provide satisfying product instead.
The product warmly welcomed in the abroad market for more than 60 counties, and the product of walking tractor is around 100000 sets per year.The largest market Include :EU,North America,South America.
why choice us
1)Professional supply with certification:CCC ISO CE DOP
2)Perfact quality program,100% test before delivery
3)One year guarantee
4)OEM cervice
5)Price is our big advantage, because we have a very strong production capacity
Shopping guide recommended
(1)Two wheel tractor 7-22hp
(2)Four wheel tractor(15-100hp) 4x2wd and 4x4wd
(3)All kinds of implments for thactor (seeder ,harvester ,Rotary cultivator,plow,Water pump ect)
