General specifications | |
Environment | Indoor / outdoor |
Operating temperature | ,-20 oC to +50 oC(de-rating characteristic applies) Option: -35 oC to +50 oc |
Storage temperature | ,-40 oC to +70 oC |
RFID system | ISO/IEC14443A/B, ISO/IEC15693, FeliCa 1, NFC reader mode, LEGIC Prime & Advant |
Payments | Smart Card, Server based Online Payments or equivalent |
Network connection | GSM / CDMA / 3G modem, 10/100 Base-T Ethernet |
Interaction Display | Full-color (7 in 800x480 TFT ) LCD display for driver interaction |
Visual Indicators | Error indication, Presence of input supply indication, Charge process indication and other relevant information |
safety protection | Over current, under voltage, over voltage, Residual current, Surge protection, Short circuit, Earth fault at input and output, Input phase reversal, Emergency shut-down with alarm, Over temperature, Protection against electric shock |
Push Button | Mushroom type emergency stop switch (Red) |
Supported Communication Protocols | OCPP1.6 |
Protection | IP54 |
