(2 years warranty, Free Tracking Platfrom (web base & Android),CE & RoHS & SGS certification)
Products Overview
Fuel Report
Application
* For vehicle tracking and security
* Intelligent fleet management
Specification
| Technical Parameters: | |
| Power Supply | +9V - +35V / 1.5A |
| Backup Battery | 650mAh |
| Dimension | 105*62*25cm |
| Weight | 95g |
| Operating temperature | -20° to 65° C |
| Humidity | 5% to 95% Non-condensing |
| GPS Module | latest GPS SIRF-Star III chipset |
| GPS Sensitivity | -158Db |
| GPS Frequency | L1, 1575.42 MHz |
| C/A Code | 1.023 MHz chip rate |
| Channels | 20 channel all-in-view tracking |
| Position Accuracy | 10 meters, 2D RMS |
| Velocity Accuracy | 0.1 m/s |
| Time Accuracy | 1 us synchronized to GPS time |
| Default datum | WGS-84 |
| Reacquisition | 0.1 sec., average |
| Hot start | 1 sec., average |
| Warm start | 38 sec., average |
| Cold start | 42 sec., average |
| Altitude Limit | 18,000 meters (60,000 feet) max. |
| Velocity Limit | 515 meters/second (1000 knots) max. |
| LED | 2 LED lights to show GPS/GSM working status. |
| Flash Memory | 4MB |
Feature
| Multiple Geo-Fence Setting,Movement Alert,overspeed Alert,tow alert,main power cut off alert etc | Fuel stolen alarm,monitor petrol level |
| GPS tracker + RFID car alarm | cut off engine remotely |
| GSM jamming detection, anti jamming | With 650mAh inbuilt rechargeable battery |
| Ublox7 GPS industrial high sensitive module | Two way tracking, GPS/intelligent GSM positioning |
| Active RFID / Passive RFID / Smart phone RFID for anti-theft and driver(student) ID identification function (Optional) | Powerful and multifunctional tracker for comprehensive Fleet management |
| Inbuilt 4MB data logger for saving position when in GSM/GPRS blind area | Get real time vehicle position address street name /Google map link by SMS |
Package & Accessories
VT310N unit: 1 unit
Wire : 1 piece
Relay: 1 piece
SOS button :1 piece
GPS antenna :1 piece
GSM antenna : 1 piece
Optional accessory :
* Fuel sensor
* Temperature sensor
* RFID kit
* Crash sensor
* Smart phone reader
* Door sensor
* Alcohol Sensor
* Speed Limiter
We provide you free GPS tracking platform ( web base & Android APP )
Welcome to login platform demo to test the function
Web Base : findtextile.com/store/gztopshine
Mobile phone link : findtextile.com/store/gztopshine
User name: officetest1
Password: 123
Web base gps tracking platform
Android APP GPS tracking platform
Our advantage
* Provide 2 free Tracking Platfrom (web base base & Android APP) .
* 2 years warranty
* All of our products have CE & RoHS & SGS certification
* Supply OEM&ODM service.
* Our engineer team could customize your personality tracking platform
* Professioal R&D team provide Customization and after-sale service lifelong .
* 100% made of industrial-grade component,GSM module have certified(CE2200)and with legal IMEI code.
Payment & Shipment:
Payment Term: PayPal /western union /TT
Shipping Term: DHL /Fedex /TNT /ARAMEX/EMX
Lead time: Samples within 1 days of delivery.bulk production within 5-7days of delivery
Welcome to Inquiry Now!!
