Specialized in manufacturing and exporting all kinds of tyres and wheels to all over the world.And we can supply wheel rims and tires,and are especially professional in truck wheel,agricultural wheel and assemblies and components for OTR wheel and engineering wheel with multi-pieces for earthmover.
And we have dealt OTR wheel for many years. The main markets of us are Australia, South Africa, South America, North America (Canada) and Asia. We also supply OEM service to many vehicle factories not only in domestic but also abroad,and now available a wide range of Earthmover wheels with diam from 20" to 63" for mine, underground, port and bridge, etc. And the rim components such as bead bands, lock rings, side rings also can be supplied.
Components are also can be supplied such as
- rim base,
- bead seat band,
- lock ring,
- side ring/flange
- Drive key
- Drive pocke
- Gutter section
- Back section
And we can supply wheel rims for below models.
785
12G
777
797
AD55
R2900
AD45
980
972
966F
950G
930G
938G
914G
140G
HM 300-2
HD 785-5
HD 785-7
We can supply all kinds of steel wheel rims for many models which you can see below.
| Dia. | Wheel size | Tire size | Application |
| 8'' | 4.33R-8 | 16x6-8 | |
| 3.00D-8 | 5.00-8 15*4 1/2-8 | ||
| 9'' | 4.00E-09 | 6.00-9 | |
| 6.00E-09 | 21x8-9 | ||
| 10'' | 5.00F-10 | 7.50-10 | |
| 6.50F-10 | 200/50-10 | ||
| 12'' | 8.00G-12 | 27x10-12 | |
| 5.00S-12 | 8.25-12 | ||
| 15'' | 5.50-15 | 7.00-15 | |
| 6.00-15 | 8.25-15 | ||
| 6.50-15 | 7.50-15 | ||
| 7.00-15 | 250-15 | ||
| 7.50-15 | 250-15 | ||
| 8.00-15 | 300-15 | ||
| 16.5-15 | 8.25-15 | ||
| 15-9.75/1.37 | 12.00-15 | ||
| 15-11.00/1.5 | 14.5-15 | ||
| 15-11.50/1.5 | |||
| 16'' | 16-8.00/0.83 | 11L-16 | |
| 16.5-8.25/0.5 | 10-16.5 | ||
| 16.5-9.75/0.5 | 12-16.5NHS | ||
| 16.5-9.75/0.7 | 12-16.5NHS | ||
| 17.5'' | 17.5-10.50/0.5 | 14-17.5NHS | |
| 18'' | 18-9.00/1.0 | 12.5/80-18 | |
| 20'' | 20-7.00/1.7 | 9.00-20 | |
| 20-7.50/1.7 | 10.00-20 | ||
| 20-8.0/1.7 | 11.00-20 | ||
| 20-8.5/1.7 | 12.00-20 | ||
| 20-9.00/1.7 | 13.00-20 | ||
| 20-10.00/1.7 | 14.00-20 | ||
| 20-10.00/1.88 | |||
| 20-10.00/2.0 | 14.00-20 | ||
| 20-11.00/1.67 | 12.5-20 | ||
| 20-12.00/2.0 | 15.5-20 | ||
| 20-13.00/1.0 | 16/70-20 | ||
| 20-14.00/2.0 | 17.5-20 | ||
| 20-15.00/1.7 | 18L-20 | ||
| 20-15.30/2.0 | 500/70-508 | ||
| 21'' | 21-11.25/2.0 | ||
| 21-13.00/1.7 | |||
| 21-17.00/2.0 | 20.00-21 | ||
| 21-18.00/1.7 | 24.00-21 | ||
| 21-18.00/1.5 | 24.00R21 | ||
| 22'' | 22-14.00/1.7 | ||
| 22-16.00/2.0 | |||
| 22-17.00/2.0 | |||
| 23'' | 23-9.25/1.75 | ||
| 23-11.00/1.5 | 14.00-23 | ||
| 23-18.00/2.0 | 24.00-23 | ||
| 24'' | 24-8.00/1.7 | 13.00-24 | |
| 24-8.50/1.7 | 12.00-24 | ||
| 24-10.00/1.7 | 12-24 14.00-24 13.00R24 | Scooptram ST2D/ST2G, CAT140G,GHH LF - 5, Sandivk LH205l, CAT12M/120M | |
| 24-11.25/2.0 | 16.00-24 | Volvo G990 | |
| 24-15.00/1.0 | 17.5-24 | ||
| 24-16.00/1.1 | 19.5-24 |
More information about us:
If you are interested with our wheel rims, welcome to contact with us.
