Model NO.
WT-CGQ006
Customized
Customized
Measure Range
0-10ppm/100ppm/, Customized
Resolution
0.001/0.01/0.1/1ppm, Customized
Certificate
CE,Atex,Cnex,ISO9001
Response Time
T90 Less Than 30s
Transport Package
Carton Boxes with Pallets
Specification
180*140*92mm (L*H*W)
Trademark
Victory
Origin
China
HS Code
9027100010
Production Capacity
50000 PCS/Year
Output Signal Type:
Digital Type
Production Process:
SemiConductor Integrated
Material:
Metal
IP Rating:
IP66
Sensitivity:
High
Certification:
CE
Fixed Industrial Gas Detector for Sulfur Dioxide Sensor Gas Leak Detector
1.Sensors use imported sensitive elements, which have the characteristics of high accuracy, strong interchangeability and high reliability;
2.The internal machine core is in the form of components. Maintenance can be accomplished only by replacing components;
3.The shell of the detector is made of die-cast aluminum and the double-chamber structure, which is designed to avoid failure because of accidental water intake, dust intake and corrosion. It is small in size and easy to install;
4.Independent acousto-optic alarm, when the gas concentration exceeds the stardard, it will send out acousto-optic alarm on the spot
2.The internal machine core is in the form of components. Maintenance can be accomplished only by replacing components;
3.The shell of the detector is made of die-cast aluminum and the double-chamber structure, which is designed to avoid failure because of accidental water intake, dust intake and corrosion. It is small in size and easy to install;
4.Independent acousto-optic alarm, when the gas concentration exceeds the stardard, it will send out acousto-optic alarm on the spot
| Name | SO2 gas detector |
| Sensor type | Electrochemistry |
| Detection range | 0-20PPM |
| Accuracy | 0.1PPM |
| Ex level | Ex d 11 C T6 Gb |
| Protection level | IP66 |
| Output signal | 4-20ma/RS485/switching walue |
| Power supply | 24VDC |
| Electronic interface | M20*1.5 |
| Distance | 1200M |
| Certifications | CE, SIL2,ATEX |
| Alarm type | Sound and light alarm+LED display |
| Shell type | Die-casting aluminum |
| Installation | Wall mounted/Tube mounted |
Q1: How many MOQ?
A: MOQ= 1piece
Q2: How about the Lead time?
A: For general parameter products,we can dispatch within 1-3 days after order confirmed.
Q3: Who take charge transportation fee?
A: Our price is FOB,exclude transportation fee,but we can quote it based on your order,you can choose.
Q4: Do you offer the guarantee for your products?
A:Yes, we offer 12 months warranty for our products.
Q5: What certificates can you support?
A: Explosion-proof CNEX,ISO9001, CE and ATEX.
Q6:Is it ok to print my logo on the gas detector?
A: Yes, OEM and ODE are available.
Q7:Can I get some discount?
A: Different products have different discount,please contact us for details.
Q8: Can I pay by T/T?
A: Yes,you can,T/T and Paypal are supported.
Q9: Do you have after sales technical guidance?
A:Yes,any questions you can show us and our technical team will service for you at any time.
Welcome to write down your requirements and more questions in the below column and Click "Send" for more information,thank you.
