Model NO.
CYX50
Output Signal Type
Analog Type
Production Process
Integration
Material
Stainless Steel
Thread Type
M
Wiring Type
Four-Wire
Measuring Medium
Liquid
Certification
CE
Customized
Customized
Range
-100kpa~10kpa~10MPa
Transport Package
Standard Package
Trademark
Huatian
Origin
Tianshui, Gansu, China
Production Capacity
500, 000PCS/Year
Type:
Piezoresistive Pressure Sensor
Component:
SemiConductor Type
For:
Diffused Silicon Pressure Transmitter
Summary
CYX50 series oil injection core pressure sensor adopts the international advanced high stability and high precision silicon pressure chip, adopts the sintering seat of stress optimization design, and is produced by the process of patch, gold wire bonding, membrane plane welding, high vacuum oil injection, pressure circulation stress relief, high temperature aging and temperature compensation.
CYX50 series assembly size and sealing mode meet the international 50 chuck interface standard, with good interchangeability.It is mainly used in medicine, food and other industries with high cleaning requirements to carry out pressure detection.
CYX50 series assembly size and sealing mode meet the international 50 chuck interface standard, with good interchangeability.It is mainly used in medicine, food and other industries with high cleaning requirements to carry out pressure detection.
Product features
1. The measuring range is - 100KPA ~ 0kpa ~ 10KPA7MPa
2. It has the form of gauge pressure G, absolute pressure A and sealing gauge pressure S
3. Constant current / constant voltage power supply
4. Isolated structure, suitable for a variety of fluid media
5. Φ 50.5mm standard pressure oiling core
6. All made of 316L stainless steel
3 Main uses
4 Technical index1. The measuring range is - 100KPA ~ 0kpa ~ 10KPA7MPa
2. It has the form of gauge pressure G, absolute pressure A and sealing gauge pressure S
3. Constant current / constant voltage power supply
4. Isolated structure, suitable for a variety of fluid media
5. Φ 50.5mm standard pressure oiling core
6. All made of 316L stainless steel
3 Main uses
1. Pharmaceutical food
2. Industrial process control
3. Gas and liquid pressure measurement
2. Industrial process control
3. Gas and liquid pressure measurement
4.1 Electrical performance
1. Power supply: ≤ 3.0mA; DC ≤ 10V DC
2. Electrical connection: 0.2mm2 4-color 100 mm silicone rubber flexible conductor
3. Common mode voltage output: 50% of current mode input (typical value), 40% of voltage type input (typical value)
4. Input impedance: 2.7K Ω ~ 5K Ω
5. Output impedance: 3.0k Ω ~ 6K Ω
6. Response time (10% ~ 90%): < 1ms
7. Insulation resistance: 500M Ω / 100V DC
8. Allowable overvoltage: 1.5 times of full scale
4.2 Structure performance
1. Diaphragm material: stainless steel 316L
2. Shell material: stainless steel 316L
3. Pressure pipe material: stainless steel 316L
4. Pin lead: Gold Plated Kovar
5. Sealing ring: silicone rubber
6. Net weight: About 160g
4.3 Environment condition
1. Vibration: no change at 10gRMS, (20-2000) Hz
2. Constant acceleration: 100g, 11ms
3. Media compatibility: liquid or gas compatible with 316L and silicone rubber
4.4 Base conditions
1. Medium temperature: (25 ± 3) ºC
2. Ambient temperature: (25 ± 3) ºC
3. Humidity: (50% ± 10%) RH
4. Environmental pressure: (86 ~ 106) kPa
5. Power supply: (1.5 ± 0.0015) MA DC
4.5 Standard range sensitivity output and optional pressure form
| Range | Full scale Output (mV) | Typical value | Pressure form | Range | Full scale Output (mV) | Typical value | Pressure form | |
| 0~10kPa | 35~60 | 45 | G | 0~600kPa | 90~120 | 100 | G/A | |
| 0~20kPa | 70~110 | 90 | G | 0~1.0MPa | 80~120 | 100 | G/A | |
| 0~35kPa | 55~80 | 70 | G/A | 0~1.6MPa | 125~185 | 150 | G/A | |
| 0~70kPa | 55~80 | 60 | G/A | 0~2.0MPa | 50~70 | 60 | G/A | |
| 0~100kPa | 60~85 | 75 | G/A | 0~3.5MPa | 100~120 | 110 | G/S/A | |
| 0~200kPa | 65~85 | 75 | G/A | 0~7.0MPa | 120~150 | 135 | S/A | |
| 0~400kPa | 60~80 | 70 | G/A |
4.6 Basic parameters
| Parameters | Typical value | Maximum | Company |
| Full scale output | 100 | 250 | MV |
| Zero output | + 1 | + 2 | MV |
| Nonlinearity | 0.2 | 0.5 | %FS |
| Hysteresis | 0.05 | 0.08 | %FS |
| Repeatability | 0.05 | 0.08 | %FS |
| Input / output Impedance | 2.6 | 5.0 | K Ω |
| Zero temperature drift note 1 | ±0.4 | ±1.0 | %FS,@25ºC |
| Sensitivity temperature drift note 2 | ±0.4 | ±1.0 | %FS, @25ºC |
| Long term stability | 0.2 | 0.3 | %FS / year |
| Exciting current | 1.5(the maximum input voltage can be 10V) | mA | |
| Insulation resistance | 500(100VDC) | M Ω | |
| Compensation temperature note 3 | 0~50;-10ºC~70ºC | ºC | |
| Working temperature | -40~+125/150 | ºC | |
| Storage temperature | -40~+125 | ºC | |
| Response time | ≤1 | MS | |
| Shell and diaphragm material | 316L stainless steel | ||
| O-ring | silicon rubber | ||
| Measuring medium | Compatible fluids with 316L and silicone rubber | ||
| Life (25 ºC) | > 1 × 108 pressure cycle (80% FS) | time | |
| Filling medium | silicone oil | ||
| Seal ring | Various specifications, user-defined | ||
| Note 1 and note 2: the typical value of zero temperature drift and sensitivity temperature drift of 0-10kpa is 0.5%FS@25ºC, maximum 1.2%FS@25ºC. Note 3: For the range of 200KPa and below, the compensation temperature is 0-50 ºC; if it is greater than 200KPa, the compensation temperature is - 10 ºC - 70 ºC. | |||
5 Selection structure
5.1 Model selection and outline drawing
5.2 Selection Guide
| Series | Range | Model | Outline drawing |
| CYX50 | -100kPa~7MPa | CYX5001 (-40ºC~125ºC) |  |
| CYX5002 (-40ºC~150ºC) |  |
5.2 Selection Guide
6 Schematic diagram and wiring mode
| IN+ (red line) - supply positive | IN - (black line) - supply negative |
| S + (yellow line) - output positive | S - (blue line) - output negative |
7 Application Tips
1. Pay attention to protect the front diaphragm and the compensation circuit board at the back end of the pressure core body, so as not to damage the performance of the pressure core body or cause damage to the core body.
2. Do not press the metal diaphragm with hands or hard objects to avoid core damage due to chip deformation or perforation.
3. The ventilation pipe at the rear of the g-core should be connected with the atmosphere; water, water vapor or corrosive media are not allowed to enter the reference chamber at the rear of the core.
4. Avoid falling and bumping, which will affect the stability of the product.
5. If there is any change in the pin lead, the label carried by the core shall prevail.
1. Pay attention to protect the front diaphragm and the compensation circuit board at the back end of the pressure core body, so as not to damage the performance of the pressure core body or cause damage to the core body.
2. Do not press the metal diaphragm with hands or hard objects to avoid core damage due to chip deformation or perforation.
3. The ventilation pipe at the rear of the g-core should be connected with the atmosphere; water, water vapor or corrosive media are not allowed to enter the reference chamber at the rear of the core.
4. Avoid falling and bumping, which will affect the stability of the product.
5. If there is any change in the pin lead, the label carried by the core shall prevail.
