Model NO.
0265420217
Thread Type
NPT
Measuring Medium
Diesel
Certification
ISO
Customized
Non-Customized
Color
Silver
Voltage
6V-24V
Warranty
1 Years
Thread
NPT1/8
Transport Package
Standard Packaging
Specification
10Bar
Trademark
Eosin
Origin
China
HS Code
9026209090
Type:
Resistance Strain Gauge Pressure Sensors
Component:
Mechanical Structure Type
For:
Strain Gauge Pressure Transmitter
Output Signal Type:
Analog Type
Production Process:
Ceramics
Material:
Metal
For measuring different media in connection with an electrical display unit. Some senders are earthed. Other senders are not earthed, i.e. earth is supplied by a separate connection. Temperature senders can be fitted with an additional warning contact in order to indicate when the temperature limit has been reached, as well as carrying out the continuous measurement.
| Version | Spring Type |
| Measuring Range | 0-10 Bar |
| Rated Voltage | 6V to 24V |
| Warning Contact | Close As Pressure Falls |
| Switching Capacity Of Warning Contact | 5 W MAX, Non-inductive |
| Operating Temperature | -25°C To +100°C |
| Resistance Range | 10 Ω to184 Ω |
| Connector | 2 Pole |
| Application | Marine, Genset, Vehicles |
Cross Interchange Parts
| Factory | Number |
| VDO | 360081029010K |
| VDO | 360081029010C |
| DEUTZ-FAHR | 12153470 |
| DAF | 0162112 |
