Model NO.
WNK80MA
Wiring Type
Two-Wire
Measuring Medium
Liquid, Gas
IP Rating
IP65
Certification
CE
Customized
Customized
MOQ
1set
Accuracy
0.5%F.S.(Typical)
Electrical Connection
Packard, M12, DIN43650, Cable
Power Supply
24VDC/12VDC/5VDC/3.3V
Measured Media
Liquid, Gas and Steam
Trademark
WNK
Origin
China
Production Capacity
2000 Sets/Week
Type:
Resonant Pressure Sensor
Component:
Mechanical Structure Type
For:
Diffused Silicon Pressure Transmitter
Output Signal Type:
Analog Type
Production Process:
Integration
Material:
Stainless Steel
Mems Assembled 0.5-4.5V 0-10V Relative Pressure Sensor for Coffee Machine
WNK80MA is a series of high performance compact pressure Transmitter, by using ASIC signal conditioning chip and dry ceramic capacitive pressure sensor. It has features of anti-corrosion, anti-wear, shock resistance and vibration resistance. Its anti-overload capacity is up to 100 times of the range, completely solved poor overload in small range of other sensors. In addition to general ranges of normal sensors, its most outstanding characteristic is the positive and negative gauge pressure function. With high output and wide range, WNK80MA is especially suitable for manufacturing of high-performance industrial control pressure transmitter and harsh environment pressure measurement.
WNK80MA Gauge/Absolute/Sealing Pressure Transmitter | |
Applicable media | Liquid, Gas |
Pressure range | 0-60bar |
Pressure measurment | Gauge Pressure, Absolute pressure, Sealing pressure |
Output | 4-20mA/0.5-4.5V/1 -5V/0-10V/I2C |
Accuracy(linearity,Hysteresis and Repeatability) | 0.5%F.S.(Typical) |
Power supply | 24VDC/12VDC/5VDC/3.3V |
Compensation temperature | -20~85ºC |
Ambient temperature | -40~125ºC |
Working temperature | -40~125ºC |
Temperature drift(zero) | ±0.15% F.S. (-20~85ºC) |
Temperature drift(full range) | ±0.15% F.S. (-20~85ºC) |
power(electrical) connect | Parkard, M12, DIN43650, Cable outlet |
Mechanical connection | G1/4, 1/4NPT, 1/8NPT, M12*1.5, customize |
Housing material | 304 stainless steel(inner core is 316 stainless steel) |
Protection | IP65 |
00:00
02:0
Q: Are you trading company or manufacturer ?
A: We are a manufacturer since the year 2004, committed to producing high accuracy, long-term stability, cost-efficient
pressure/level/temperature measuring instruments.
Q: What's your quality control system?
A: Our factory is cerrified under ISO 9001-2015. All products are completed with temperature compensation and 48 hours aging test before shipment.
Q: What is the warranty of your products?
A: 12 month from shipment date, for non-man-made damages.
Q: Shipping and Delivery
A: Small orders are delivered with DHL, Fedex, TNT, UPS , with delivery time in 4 - 5 business days. Large orders are recommended to ship by sea
A: We are a manufacturer since the year 2004, committed to producing high accuracy, long-term stability, cost-efficient
pressure/level/temperature measuring instruments.
Q: What's your quality control system?
A: Our factory is cerrified under ISO 9001-2015. All products are completed with temperature compensation and 48 hours aging test before shipment.
Q: What is the warranty of your products?
A: 12 month from shipment date, for non-man-made damages.
Q: Shipping and Delivery
A: Small orders are delivered with DHL, Fedex, TNT, UPS , with delivery time in 4 - 5 business days. Large orders are recommended to ship by sea
