Model NO.
HPM270
Thread Type
G
Wiring Type
Two-Wire
Measuring Medium
Liquid Gas Steam
IP Rating
IP65
Certification
ISO9001
Customized
Customized
Sensor Type
Pressure Sensor
Pressure
-100kPa...0~1kPa...60MPa
Pressure Reference
Gauge, Absolute, Sealed Gauge
Accuracy
0.2%F.S.
Over Pressure
1.5 times pressure range of full scale
Supply
24VDC
Output
4~20mADC
Working Temp
-30~85ºC
Storage Temp
-40~120ºC
Protection of Shell
IP65
Electrical
Dedicated shield cable 1.5 meters
Transport Package
Carton
Trademark
HangJia Sensor
Origin
China
HS Code
90262010
Production Capacity
50000 Pieces / Year
Type:
Smart Pressure Transmitter
Component:
SemiConductor Type
For:
Diffused Silicon Pressure Transmitter
Output Signal Type:
Analog Type
Production Process:
Injection
Material:
Stainless Steel
Product Overview:
HPM270 Intelligent Digital Display Pressure Transmitter adopts intelligent technology to show the world-class craft of pressure transmitter. It has many great features such as compact construction, sturdiness, light weight, easy installation, convenient use and maintenance free. The zero-scale and full-scale are adjustable. It also has wide range of span shift. It is with LCD, and the parameters of transmitter can be configured by keying. The product can be used in various occasions and in hostile environment.
Features:
·Protective electric shell, ingress protection IP65
·LCD field display, high accuracy and high stability
·Configuration operation, wide range of span shift
·Suitable for various hostile occasions
Parameters:
Structure Drawings:
Electrical Connection:
Ordering Guide:
Related Products:
Certification:
FAQ:
1. Q: Are you manufacturer or trading company?
A: We are manufacturer which focuses on sensor for 10 years.
2. Q: What's your quality control system?
A: MC, ISO9001, CE Certificated.
3. Q: What is the warranty of your products?
A: Our warranty time is 18 months after shipment.
HPM270 Intelligent Digital Display Pressure Transmitter adopts intelligent technology to show the world-class craft of pressure transmitter. It has many great features such as compact construction, sturdiness, light weight, easy installation, convenient use and maintenance free. The zero-scale and full-scale are adjustable. It also has wide range of span shift. It is with LCD, and the parameters of transmitter can be configured by keying. The product can be used in various occasions and in hostile environment.
Features:
·Protective electric shell, ingress protection IP65
·LCD field display, high accuracy and high stability
·Configuration operation, wide range of span shift
·Suitable for various hostile occasions
Parameters:
| Measuring Medium | Liquid, Gas, Steam |
| Pressure Range | -100kPa...0~1kPa...60MPa |
| Overload | 1.5 times pressure range of full scale |
| Pressure Type | Gauge, Absolute or Sealed Gauge |
| Accuracy | ±0.2%FS(Representative), ±0.5%FS(Maximum) |
| Long-term Stability | ±0.1%FS/year(Representative), ±0.2%FS(Maximum) |
| Temperature Coefficient of Zero | ±0.03%FS/ºC(Reference 25ºC) |
| Temperature Coefficient of Full Scale | ±0.03%FS/ºC(Reference 25ºC) |
| Working Temp | -30~85ºC |
| Storage Temp | -40~120ºC |
| Supply Voltage | 24VDC |
| Output Signal | 4~20mADC |
| Output Mode | Two wire |
| Load Resistance | ≤(U-12)/0.02Ω |
| Insulation Resistance | 100MΩ,500VDC |
| Ingress Protection of Shell | IP65 |
| Electrical Connection | Dedicated shield cable 1.5 meters |
Structure Drawings:
 |  | ||||||
Electrical Connection:
Ordering Guide:
| Item NO. | Type | |||||||
| HPM270 | Intelligent Digital Display Pressure Transmitter | |||||||
| Pressure Range | Measuring Range | |||||||
| (0~X)kPa | Fill out X directly | |||||||
| Code | Output Signal | |||||||
| B1 | (4~20)mA | |||||||
| Code | Thread Spec | |||||||
| P1 | M20×1.5 | |||||||
| P4 | G1/2 | |||||||
| Code | Electrical Connection | |||||||
| C2 | Cable Outlet | |||||||
| Code | Structure&Material | |||||||
| Diaphragm | Interface | Shell Material | ||||||
| M1 | 316L | 316L | Stainless Steel | |||||
| M2 | 316L | 316L | 316L | |||||
| M3 | Tantalum | Hastelloy | 316L | |||||
| M4 | Titanium | Titanium | 316L | |||||
| X | Other | |||||||
| Code | Additional Functions | |||||||
| G | Gauge Pressure(Default) | |||||||
| A | Absolute Pressure | |||||||
| S | Sealed Gauge Pressure | |||||||
| v | Fluororubber O-Ring(Default) | |||||||
| j | Buna-n O-Ring | |||||||
| h | All-welded without O-Ring | |||||||
| L | atmospheric pressure measurement within 10kPa | |||||||
| W | water-proof and ventilated treatment | |||||||
| HPM270 | (-2~2)kPa | B1 | P1 | C2 | X | G v L W | ||
Related Products:
Certification:
FAQ:
1. Q: Are you manufacturer or trading company?
A: We are manufacturer which focuses on sensor for 10 years.
2. Q: What's your quality control system?
A: MC, ISO9001, CE Certificated.
3. Q: What is the warranty of your products?
A: Our warranty time is 18 months after shipment.
4. Q: What is lead time of your product?
A: Normally, our factory lead time is within 10~15 working days for products without customization. You can also check lead time detail with our sales depending on different items.5. Q: Do you provide customized products?
A: Yes, we can laser mark your logo on products; OEM and ODM customization are welcomed.6. Q: What is your MOQ?
A: We have no MOQ limit, small quantity order is acceptable.7. Q: What's the transport?
A: Express such as DHL, FedEx, TNT, UPS for freight prepaid; and we can also use your own courier account to do the freight collect. For more goods we can arrange by air or by Sea.8. Q: What is your terms of payment ?
A: We could accept T/T, Paypal, WU.
