50~5000kg Tension pressure transducer Stainless/Alloy steel tensile -compressive Load Cell S type tension force sensor
Descriptions
50,100,200,500,1000,2000,3000,5000kg S Beam Load Cell FA305 is a model which is in S Beam Load Cell category of our brand FIBOS FA3-Series, S Beam Load Cell FA305 can be used to measure load 50,100,200,500,1000,2000,3000,5000kg capacity, its Cable size is diameter 5.4x3000mm
| Product name | S Beam Load Cell |
| Capacity | 50,100,200,500,1000, 2000,3000,5000kg |
| Rated output | 2.0±0.25%mV/V |
| Zero Balance | ±0.01mV/V |
| Non-linearity | ≤0.018%F.S. |
| Hysteresis | ≤0.018%F.S. |
| Repeatability | ≤0.024%F.S. |
| Input impedance | 385±10Ω |
| Output impedance | 350±5Ω |
| Insulation resistance | ≥5000MΩ/100VDC |
| Recommended excitation | 5~15V |
| Maxmum excitation Voltage | 20V |
| Compensated Temp Range | -10~40 ºC |
| Operating Temp Range | -30~70 ºC |
| Temp.effect on output | 0.014%F.S./10 ºC |
| Temp.effect on zero | 0.017%F.S./10 ºC |
| Safe overload | 150%F.S. |
| Ultimate overload | 300%F.S. |
| Cable size | diameter 5.4X3000mm |
| Weight | - |
| Material | Stainless steel/alloy steel |
