Model NO.
MD-CB101
Thread Type
No
Measuring Medium
Gas
IP Rating
IP65
Certification
ISO
Customized
Customized
Output
0.5~4.5V/4~20mA
Transport Package
Carton
Origin
Shanghai
Type:
Capacitive Pressure Sensor
Component:
SemiConductor Type
For:
Capacitive Pressure Transmitter
Output Signal Type:
Analog Type
Production Process:
Ceramics
Material:
Ceramics
Product Description:
MD-CB101 is a series of oil and gas pressure ceramic sensors specially designed for commercial vehicles, ships and construction machinery. Have features of high reliability, high precision, etc. The analog signal output after linearity check and temperature compensation is proportional to the supply voltage and a linear function with the input pressure, as a linear function of input pressure.The working pressure range of CB-0100-SDH is 0~10Bar gauge pressure, The corresponding output voltage range is 0.5 ~ 4.5V.
Technical characteristics:
Maximum 1.5% error in the range of 0~85ºC
Temperature compensation range -40~125ºC
Operation voltage: 5±0.25V
High voltage 10V protection, reverse connection protection
High reliability, low drift
Applications:
Automobile oil pressure
Water pressure sensor
Urea pressure sensor
Refrigerant pressure sensor
industrial control
Specification:
