Model NO.
JSA0074
Origin
China
Production Capacity
50000 Set
Material:
Pcbr
Position:
Rear
OEM:
Yes
Type:
Suspension Spring
Transport Package:
Box
Specification:
black
SN130190BL2-H/double convoluted air suspension /airspring BELLOW rubber airride shock absorber/pneumatic parts
This is universal type: SN130190BL2-H
ITEM NAME: SN130190BL2-H
material: PCBR /Natural rubber
end plates/lock rings: machine made aluminum/Steel
OEM / ODM: yes
Natural /Max/Min diameter at 110PSI: 130mm/145mm/127mm
Natural height/Max Height /Min height at 110PSI: 190mm/226mm/85mm
Max working pressure: 110PSI
N.W: 2kg
air port: 1/8NPT
LOAD CAPACITY: 605kg
Sealing design: Double inner sealing
SAFE WORKING PRESSURE: ≤145PSI
WORKING TEMPERATURE: -40ºC~70ºC
This is universal type: SN130190BL2-H
ITEM NAME: SN130190BL2-H
material: PCBR /Natural rubber
end plates/lock rings: machine made aluminum/Steel
OEM / ODM: yes
Natural /Max/Min diameter at 110PSI: 130mm/145mm/127mm
Natural height/Max Height /Min height at 110PSI: 190mm/226mm/85mm
Max working pressure: 110PSI
N.W: 2kg
air port: 1/8NPT
LOAD CAPACITY: 605kg
Sealing design: Double inner sealing
SAFE WORKING PRESSURE: ≤145PSI
WORKING TEMPERATURE: -40ºC~70ºC
