Model NO.
MAH
Contact Group
1 Group
Contact Arrangement
1A 1b 1c 2A
Contact Material
Silver Alloy
Structure
Dust Protected or Sealed
Coil Voltage
12VDC 24VDC
Outline Dimensions
26*26*25mm
Current
40A 60A
Contact Load
High Power
Transport Package
100PCS/Box 1000PCS/Inner Carton 2000PCS/Big Carton
Trademark
MEISHUO
Origin
China
Production Capacity
32000000 Piece/Pieces Per Year
Warranty:
12 Months
Application:
Auto
Protect Feature:
Sealed
Terminal Form:
QC
Unit Weight:
33G
Construction:
Dust Protected or Sealed
MEISHUO MAH 30A 40A 60A 12VDC 24VDC 4Pin 5Pin Types of Automotive Relay
Product Description
Product Description
MEISHUO MAH 30A 40A 60A 12VDC 24VDC 4Pin 5Pin types of automotive relay
Product Name | Automotive relay MAH | Coil Voltage | 12VDC 24VDC |
Brand | Meishuo.. | Colour | Black |
Ambient Temperature | ..-40~+105 | Place of Product | Zhejiang Province,China |
Terminal Form | QC. | Modes of packing | Packed in three cartons |
Size | 26*26*25mm | Unit Weight | 33g |
Features:
* 40A & 60A switching capability
* 40A & 60A switching capability
* 4 Kinds of contact arrangement available
* Various mounting terminations available
* Dust protected type and sealed type available
* Outline Dimensions : 27.8*27.8*25.1mm
* Various mounting terminations available
* Dust protected type and sealed type available
* Outline Dimensions : 27.8*27.8*25.1mm
Detailed Images
Outline Dimensions
Wiring Diagram
Wiring Diagram
Packing&Shipping
* 50pcs /plastic box
* 10 plastic boxes/master box
* 500pcs/master box
* shockproof packing: packing filler corrugated board
* Meas:45*40*22cm
* G.W.:18KGS 18.5KGS 21KGS
* N.W.:17KGS, 17.5KGS, 17.5KGS
* 500pcs/master box
* shockproof packing: packing filler corrugated board
* Meas:45*40*22cm
* G.W.:18KGS 18.5KGS 21KGS
* N.W.:17KGS, 17.5KGS, 17.5KGS
FAQ
Q1.Can I have sample oder for relay?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about lead time?
A:Sample needs 3-9 days, mass production time needs 1-2 weeks for order quantity more than
Q3. Do you have any MOQ limit for relay order?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long dose it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How do you proceed order for relay ?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it ok to print my logo on relay product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
