Model NO.
8224-11
Bonding Type of Magnetic Field Winding
Inner Bonding
Brushless Alternator Type
Claw-pole Type
Voltage Adjuster Type
Electromagnetic Vibratory
Voltage
12V
Head Cover Position
Front
Rotation
Cw
Transport Package
Neutral Packing
Origin
Yancheng
HS Code
85115090
Production Capacity
20000 Per Year
After-sales Service:
1 Year
Warranty:
1 Year
Type:
Alternator
Structure:
Silicon Rectification Generator
Rectifier Structure:
Six Tubes
Current Level:
9(≥90A)
| Unit Type | Alternator |
| Part Type | UNIT |
| Voltage | 12 |
| Rotation | CW |
| Dimension | Replacement 105A CS130D Unit: Mtg. Ear 1 Hole: 10.0mm Unthreaded Mtg. Ear 2 Hole: M8-1.25 Threaded B+ Terminal: M8-1.25 |
| Amperage | 105 |
| Clock | 11 |
| Pulley Class | S6 |
| Regulator | IR |
| Fan Type | IF |
| Manufacturer | DELCO |
| Brief | CHEVROLET CAMARO 3.8L 1999 PONTIAC FIREBIRD 3.8L 1999 6-GROOVE PULLEY 62mm OD DELCO CS130D 11:00 PLUG ADDL INFO: #9734 REGULATOR ADDL INFO: REPLACE w/#705 REGULATOR FOR MORE APPLICATIONS |
| Detailed | The Later #703 and #9734 Are I-Terminal Regulators (vs. F-Terminal in the #705), But Turn On the Same Way as the #705. Problems With Trying to Use the 8200-11 in These Applications Was That the Alternator Would Not Always Turn On in the Car Unless the Correct Version of the #703 (or the #9734) Was Used. Rather Than Try to Determine a Test for the #703 or to Add Additional Part Numbers to Try to Cover This It Was Decided to Merge These Into the 8224-11, as the Field Reports That the #705 Works Despite the I vs. F-Terminal Difference (The I-Terminal Does Not Appear to Be Used in the Applications Affected). The 10480307 Originally Came With the #9734 Regulator, But Because This Turns On Like the #705 (and a #703 Will Not Turn On in the Same Fashion) We are Merging This Into the 8224-11 So That a #705 Is Used. The #705 Will Replace the #97634 in These Applications According to Those Who Have Done it in the Field. |
| MFG# | MFG NAME |
|---|---|
| 400-12109 | ARROWHEAD |
| 400-12109 | J & N |
| ADR0126 | ARROWHEAD (OLD) |
| 8224-11 | LESTER |
| 240-6135 | PIC |
| 321-1753 | AC DELCO |
| 334-2468 | AC DELCO |
| MCA8182-11 | ACE |
| 110-8224 | BARSANCO |
| 8224-11 | BBB |
| 8224-11 | BBB NEW |
| N8224-11 | BBB NEW |
| B8224-11 | BBB PACE |
| 186-6312 | BECK ARNLEY |
| 188-6312 | BECK ARNLEY NEW |
| 112866 | CARGO |
| 112867 | CARGO |
| 10464409 | DELCO |
| 10480307 | DELCO |
| RM1264 | DELPHI |
| 210-5118 | DENSO FIRST TIME FIT |
| A-1434 | DIXIE |
| A-1434N | DIXIE NEW |
| CS130D | FAMILY |
| 47-2041 | MINNPAR |
| 8194611 | MPA |
| 13-4594D | NAPA |
| 13-4722D | NAPA |
| 13-4731D | NAPA |
| 13-4733D | NAPA |
| 13-4733K | NAPA |
| 1N4733D | NAPA NEW |
| 1N-4733D | NAPA POWER NEW |
| 213-4722D | NAPA POWER PREMIUM PLUS |
| 213-4731D | NAPA POWER PREMIUM PLUS |
| 213-4733D | NAPA POWER PREMIUM PLUS |
| 213-4743D | NAPA POWER PREMIUM PLUS |
| 213-4753D | NAPA POWER PREMIUM PLUS |
| 13-4722D | NAPA POWER SUPREME |
| 13-4731D | NAPA POWER SUPREME |
| 13-4733D | NAPA POWER SUPREME |
| 13-4743D | NAPA POWER SUPREME |
| 13-4753D | NAPA POWER SUPREME |
| ALT-1425 | NSA |
| 21099 | REMY LIGHT DUTY |
| 8224-11 | USA INDUSTRIES |
| 8200N | WAI |
| 1-1985-01DR | WAI (OLD) |
| 90-01-4236 | WILSON |
| 90-01-4349 | WILSON |
| 90-01-4349 | WILSON NEW |
| 90-01-4349N | WILSON NEW |
