Model NO.
UCP215
Brand
Fkd
UCP215 Weight
6.14kg
Company Area
100, 000sqm(Plant 65000+ Sqm)
Housing Material
Cast Iron(Ht200)
Bearing Seal Type
Double Seal, F Seal, Triple Seal
Transport Package
Polybag+ Individual Color Box+ Carton + Pallet
Specification
P0 or ABEC-1
Trademark
FKD, HHB, FE
Origin
Xingtai, Hebei
HS Code
84832000
Production Capacity
600, 000PCS Per Mouth
Type:
Pillow Blocks
Material:
Chrome Steel
Tolerance:
P0
Certification:
ISO9001
Clearance:
C0
ABS:
Without ABS
Product name: Pillow Blocks
Product brand: FKD, FE, HHB
Bearing items: UCP200 UCPX00 UCP300
Product packing: Plastic bag + individual color box + carton + pallet
Insert bearing: UC200, UCX00, UC300, SA200, SB200, UK200, HC200, SER200
Bearing material: Chrome steel (Gcr15)
Housing material: Cast iron (HT200), Stainless steel, Plastic resin, Zinc alloy, Pressed steel
Steel NO. C(%) Si(%) Mn(%) S(%) P(%) Cr(%)
Gcr15 0.95-1.05 0.15-0.35 0.20-0.40 ≤ 0.020 ≤ 0.027 1.30-1.65
Pillow block, also known as plummer block or bearing housing, is a pedestal used to provide support for a rotating shaft with the help of compatible bearings & various accessories. Housing material for a pillow block is typically made of cast iron or cast steel.
Pillow Block Bearings are composed of a single row deep groove ball bearings with seals at both sides and spherical outside surface, and a housing, suitable for simple support.
Pillow Blocks are for mechanical equipment, like agricaltural, metallurgical, textile and printing machinery.
Product brand: FKD, FE, HHB
Bearing items: UCP200 UCPX00 UCP300
Product packing: Plastic bag + individual color box + carton + pallet
Insert bearing: UC200, UCX00, UC300, SA200, SB200, UK200, HC200, SER200
Bearing material: Chrome steel (Gcr15)
Housing material: Cast iron (HT200), Stainless steel, Plastic resin, Zinc alloy, Pressed steel
Steel NO. C(%) Si(%) Mn(%) S(%) P(%) Cr(%)
Gcr15 0.95-1.05 0.15-0.35 0.20-0.40 ≤ 0.020 ≤ 0.027 1.30-1.65
Pillow block, also known as plummer block or bearing housing, is a pedestal used to provide support for a rotating shaft with the help of compatible bearings & various accessories. Housing material for a pillow block is typically made of cast iron or cast steel.
Pillow Block Bearings are composed of a single row deep groove ball bearings with seals at both sides and spherical outside surface, and a housing, suitable for simple support.
Pillow Blocks are for mechanical equipment, like agricaltural, metallurgical, textile and printing machinery.
