M8 Blind Nuts Phoenix SP 1B 07 Convoluted Air Springs
Refer No.
Phoenix SP 1 B 07
Phoenix SP1 B 07
Phoenix SP1B 07
Phoenix SP1B07
Phoenix SP 1B 07
Phoenix SP 1B07
Specifications and Detailed Technical Parameters: 1B5022
Nut/blind nut
Top plate screw (nut) teeth: 2×M8×1.25
The screw center distance of the top cover plate: 53mm
Screw (nut) teeth of the bottom cover plate: 2×M8×1.25
The screw center distance of the bottom cover plate: 53mm
Air hole/air inlet/air fittings
Air hole/air inlet: G1/4
The distance between the screw center and air inlet/air hole/air fittings: 26mm
Cover plate
Top plate diameter: 135 mm
Diameter of the bottom cover: 135 mm
Bell rubber bellows
MAX. Rubber Bellow Diameter: 215mm
Stroke: Minimum 50mm to Maximum 115mm
Bumper block/bumper block
No bumper block
Belt loop/Belt loop
Without belt loop
Other Types of Phoenix air ballons we can offer
| SP 1 B 04 | SP 2 B 05 R-a | 2B 07 R | 2B07R |
| SP 1 B 05 | SP 2 B 07 R | 2B 12 R | 2B12R |
| SP 1 B 07 | SP 2 B 12 R | 2B 12 R-3 | 2B12R-3 |
| SP 1 B 12 | SP 2 B 12 R-1 | 2B 15 R | 2B15R |
| SP 1 B 22 | SP 2 B 12 R-2 | 2B 20 R | 2B20R |
| SP 1 B 34 | SP 2 B 12 R-3 | 2B 20 R-9 | 2B20R-9 |
| SP1B04 | SP 2 B 22 R | 2B 21 R | 2B21R |
| SP1B05 | SP 2 B 34 R | 2B 21 R-9 | 2B21R-9 |
| SP1B07 | SP 2 B 34 R-b | 2B 22 R | 2B22R |
| SP1B12 | SP2B05R-a | 2B 22 R a-9 | 2B22Ra-9 |
| SP1B22 | SP2B07R | 2B 34 R | 2B34R |
| SP1B34 | SP2B12 R | 2B 34 R-b | 2B34R-b |
| SP2B12R-1 | 2B 49 R-a | 2B49R-a | |
| SP2B12R-2 | 2B 49 R-b | 2B49R-b | |
| SP2B12R-3 | 2B 85 R | 2B85R | |
| SP2B22R | 2B 85 R-a | 2B85R-a | |
| SP2B34R | |||
| SP2B34R-b |
The reason why the rubber air spring can replace the pneumatic or hydraulic cylinder is because it has the following outstanding advantages
Low design height: Compared with the traditional cylinder, the air bag air spring has no piston rod, which can greatly reduce the design height and make the structure more compact.
Low cost of ownership: Compared to conventional cylinders, air bag air springs are not only low-cost to purchase, but also cost less due to their long service life and no maintenance.
Economical and easy installation: When not inflated, the air bag air spring is quick and easy to install, saving time and money. Moreover, the product has good elasticity and can compensate for small deviations.
Allowable lateral eccentricity: The lateral eccentricity of the airbag air spring can be up to 30mm, within which the reliability of the work can still be maintained. Unlike air or hydraulic cylinders, bladder cylinders have no seals that can jam or wear, and do not require precision guides that are susceptible to dust and other impurities.
Frictionless = Maintenance free: Airbag air springs work effectively even in poor operating conditions. Since there are no parts (seals) that rub against each other in the bladder-type cylinder, there is no wear even when working in an environment with a lot of dust, particles or sediment.
The related picture of 1B5022
Company Profile
Guangzhou Guomat air spring Co., Ltd. was established in 2008 and is located in Guangzhou, the capital city of Guangdong Province. The company's production plant covers an area of 20,000 square meters and is located in Taihe Town, Baiyun District, Guangzhou City. With the continuous development of the company, it is gradually equipped with modern workshops and advanced rubber air spring equipment. It is one of the important air spring production bases in China. At the same time, Gomart used domestic advanced air spring processing equipment and introduced foreign air spring production technology, combined with the company's unique production process, and strictly implemented production in accordance with international standards to produce advanced products. All products comply with ISO9001, ISO/IS16949 standards.
The main products of Guangzhou Guomat air spring Co., Ltd. are: rubber air springs, air suspension springs, rubber air springs for automobiles, airbags for passenger cars and trucks, industrial air springs, etc. The products cover buses, luxury cars, trucks, Commercial vehicles, rail vehicles, industrial machinery, industrial equipment and other industries. The company has hundreds of models and styles of products. At the same time, it can also carry out directional transformation and design of products according to the special needs of users, providing users with one-stop service.
Factory workshop
FAQ
Q1:Can you produce the product according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q2: What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q3: What certification does your product pass?
A: Our products are certified to ISO/TS16949:2009 international quality standards. Please rest assure that we have very strict Quality Control Systems.
Q4 : Can I use my own logo?
A:Sure. We can do as per the customer's requirements.
