Nmrv075 Worm Gearbox Motor Output Flange, Reducer, Worm Gearbox

Product detail

Model NO.

NMRV075

Hardness

Hardened

Installation

Vertical Type

Single-Step

Worm and Wormwheel

Gearing Arrangement

Output Torque

66n.M~~304n.M

Rated Power

0.25~~4.0kw

Input Speed

1400rpm

Output Speed

14~~186rpm

Speed Ratio

7.5/10/15/20/25/30/40/50/60/80/100

Place of Origin

Zhejiang, China (Mainland)

Housing Material

Aluminium Alloy

Worm Gear Material

Chromium Alloy 20crmnti

Material

Aluminium Alloy

Manipulate Way

Semi-Automatic Manipulation

Manufacturing Method

Cast Gear

Toothed Portion Shape

Spur Gear

Changes Way

Stepless

Transport Package

Carton and Wood Pallet

Specification

225X215X285mm

Trademark

Chenxin

Origin

Zhejiang, China (Mainland)

Production Capacity

30000 Set/ Month

Application:

Machinery, Agricultural Machinery, Industry

Function:

Speed Changing, Speed Reduction

Layout:

Cycloidal

Nmrv075 Worm Gearbox Motor Output Flange
MNRV075 Worm Gearbox Speed Reducer Machine

Features
1.Wide transmission rate, strong output torque
2.Compact mechanical structure, light weight, small volume&Good heat-dissipating
3.Smooth operation with lower noise or vibration
4.Easy mounting, free linking, high efficiency
5. PERFECT SUBSTITUDE FOR MOTOVARIO AND BONFIGLIOLI PRODUCTS
Applications
Wide range of application,including light industry of food &beverage, Cement,
package,construction material,chemicals and etc.

Performance parameter for RV series worm gear speed reducer

Motor power	Model	speed ratio	output speed	output toruqe
0.25kw 1400rpm	NMRV075	60	24rpm	68.0N.M
	NMRV075	80	18rpm	80.0N.M
	NMRV075	100	14rpm	94.0N.M
0.37kw 1400rpm	NMRV075	40	35rpm	74.0N.M
	NMRV075	50	28rpm	88.0N.M
	NMRV075	60	24rpm	97.0N.M
	NMRV075	80	18rpm	119.0N.M
	NMRV075	100	14rpm	139.0N.M
0.55kw 1400rpm	NMRV075	25	56rpm	76.0N.M
	NMRV075	30	47rpm	87.0N.M
	NMRV075	40	35rpm	108.0N.M
	NMRV075	50	28rpm	128.0N.M
	NMRV075	60	24rpm	144.0N.M
	NMRV075	80	18rpm	177.0N.M
	NMRV075	100	14rpm	206.0N.M
0.75kw 1400rpm	NMRV075	15	94rpm	66.0N.M
	NMRV075	20	70rpm	85.0N.M
	NMRV075	25	56rpm	101.0N.M
	NMRV075	30	47rpm	117.0N.M
	NMRV075	40	35rpm	147.0N.M
	NMRV075	50	28rpm	174.0N.M
	NMRV075	60	24rpm	196.0N.M
	NMRV075	80	18rpm	250.0N.M
1.1kw 1400rpm	NMRV075	10	140rpm	66.0N.M
	NMRV075	15	94rpm	95.0N.M
	NMRV075	20	70rpm	122.0N.M
	NMRV075	25	56rpm	148.0N.M
	NMRV075	30	47rpm	171.0N.M
	NMRV075	40	35rpm	216.0N.M
	NMRV075	50	28rpm	263.0N.M
	NMRV075	60	24rpm	297.0N.M
1.5kw 1400rpm	NMRV075	7.5	186rpm	68.0N.M
	NMRV075	10	140rpm	89.0N.M
	NMRV075	15	94rpm	129.0N.M
	NMRV075	20	70rpm	166.0N.M
	NMRV075	25	56rpm	202.0N.M
	NMRV075	30	47rpm	233.0N.M
	NMRV075	40	35rpm	299.0N.M
2.2kw 1400rpm	NMRV075	7.5	186rpm	99.0N.M
	NMRV075	10	140rpm	131.0N.M
	NMRV075	15	94rpm	189.0N.M
	NMRV075	20	70rpm	249.0N.M
	NMRV075	25	56rpm	304.0N.M
	NMRV075	30	47rpm	247.0N.M
3.0kw 1400rpm	NMRV075	7.5	186rpm	135.0N.M
	NMRV075	10	140rpm	178.0N.M
	NMRV075	15	94rpm	258.0N.M
4.0kw 1400rpm	NMRV075	7.5	186rpm	180.0N.M
4.0kw 1400rpm	NMRV075	10	140rpm	237.0N.M

Technical data

Model	RV025 030 040 050 063 075 090 110 130 150
Single unit versions	NMRV - fitted for motor flanged coupling, NRV - with input shaft, NMRV-E motor flanged coupling with worm extension shaft, NRV-E with double extension worm shaft,
Power	0.06----15KW
Single unit reduction ratio	1:5 7.5 10 15 20 25 30 40 50 60 80 100
Output torque	2.6---1195N.M
Worm shaft	20CrMnTi with carburizing and quenching.The hardness of surface is 56-62HRC with carbonized layer 0.5-0.8mm
Worm wheel	worm mandrel is HT250,and worm ring gear,ZQSn10-1
