Model NO.
SRC01P
Hardness
Hardened
Installation
Vertical Type
Step
Double-Step
Type
Worm and Wormwheel
Speed Ratio
40.1
Input Speed
1400rpm
Output Speed
34.9rpm
Output Torque
144nm
Housing Material
Aluminium Alloy
Color
Silver / Coustomzied
Certification
ISO9001:2008
Material
Stainless Steel
Changes Way
Stepped
Transport Package
Carton
Specification
ISO9001: 2008
Trademark
chenxin
Origin
China Zhejiang
HS Code
848340900
Production Capacity
30000set/Month
Application:
Electric Cars, Motorcycle, Machinery, Industry
Function:
Distribution Power, Clutch, Change Drive Torque, Speed Increase
Layout:
Coaxial
Taizhou Sihai Machinery Co., Ltd.has been specialising in the manufacture and export of RV series worm gearboxes and other power transmission products for years, dedicated to provide to our customers good quality products in competitive prices. The main products are RV series worm gear speed reducers, UD series mechanical speed variators, G3 series helical geared motors and the specially designed reducers for polishing machines. Our products are widely used in the mechanical apparatus for foodstuff, ceramics, package, chemical, printing, and plastics, etc.
Guided by the idea, "Quality is the very key.". the company proceeds in strict quality control to all the products, complying with the requirements of ISO9001:2008, and certificated, which has enabled our products to have enjoyed the successful sales, popularity and good reputation among the markets of Europe, Mid-east, and Souteast Asia..
Innovation, good quality, customers' satisfication, and excellent service are the principles of the company. All customers at home and abroad are warmly welcome to contact us and negotiate for mutual business expansion.
Technical Features
The high degree of modularity is a design feature of SRC helical gearboxes range. It can be connected respectively with motors such as normal motor, brake motor, explosion-proof motor, frequency conversion motor, servo motor, IEC motor and so on. This kind of product is widely used in drive fields such as textile, foodstuff, ceramics packing, logistics, plastics and so on. It is possible to set up the version required using flanges or feet.
Products characteristics
SRC series helical gear units has more than 4 types. Power 0.12-4kw; Ratio 3.66-54; Torque max 120-500Nm. It can be connected (foot or flange) discretionary and use multi-mounting positions according to customers requirements.
l Ground-hardened helical gears;
l Modularity,can be combined in many forms;
l Aluminium casing, light weight;
l Gears in carbonize hard, durable;
l Universal mounting;
l Refined design,space effective and low noise
Guided by the idea, "Quality is the very key.". the company proceeds in strict quality control to all the products, complying with the requirements of ISO9001:2008, and certificated, which has enabled our products to have enjoyed the successful sales, popularity and good reputation among the markets of Europe, Mid-east, and Souteast Asia..
Innovation, good quality, customers' satisfication, and excellent service are the principles of the company. All customers at home and abroad are warmly welcome to contact us and negotiate for mutual business expansion.
Technical Features
The high degree of modularity is a design feature of SRC helical gearboxes range. It can be connected respectively with motors such as normal motor, brake motor, explosion-proof motor, frequency conversion motor, servo motor, IEC motor and so on. This kind of product is widely used in drive fields such as textile, foodstuff, ceramics packing, logistics, plastics and so on. It is possible to set up the version required using flanges or feet.
Products characteristics
SRC series helical gear units has more than 4 types. Power 0.12-4kw; Ratio 3.66-54; Torque max 120-500Nm. It can be connected (foot or flange) discretionary and use multi-mounting positions according to customers requirements.
l Ground-hardened helical gears;
l Modularity,can be combined in many forms;
l Aluminium casing, light weight;
l Gears in carbonize hard, durable;
l Universal mounting;
l Refined design,space effective and low noise
| 1 | Code for gear units series |
| 2 | No F code means foot mounted.With F code B5 flange mounted.With Z code B14 flange mounted |
| 3 | Specification code of gear units 01 |
| 4 | I,II,III,B5 Output flange specification,default I not to write out is ok |
| 5 | IEC: Input flange HS: shaft input |
| 6 | Transmission ratio of gear units |
| 7 | M1:Mounting position, default mounting position M1 not to write out is ok |
| 8 | Position diagram for motor terminal box,default position o°(R) not to write out is ok |
| 9 | No mark means without motor Model motor(poles of power) |
| 10 | Voltage - frequency |
| 11 | Coil in position for motor, default position S not to write out is ok |
