Model NO.
PLE42/PLE42-SW/PLF42/PS42
Type
Planetary Gear Box
Applicable Industries
Manufacturing Plant, Machinery Repair Shops, Print
Input Flange Diameter
42mm Frame
Gearing Arrangement
Planetary
Output Speed
43 Rpm- 750 Rpm
Output Torque
5 - 12n.M
Rated Input Speed
3000rpm
Speed Ratio
4,5,7,10. Double Stage:16,20,25,28,35,40,50,70
Warranty
1 Year
Certification
ISO9001 & CE
Housing Material
20crmn
Material of Shaft
Standard Material
Material of Gear
High Precision Grinding
Customized Support
OEM, ODM
Transport Package
Carton Box or Wooden Box
Specification
42mm
Trademark
HPS
Origin
China
HS Code
8483402000
Production Capacity
500000PCS/Year
Application:
Motor, Machinery, Marine, Agricultural Machinery, Laser Cutting Machine
Function:
Change Drive Torque, Change Drive Direction, Speed Changing, Speed Reduction, Speed Increase
Layout:
Coaxial
Hardness:
Hardened Tooth Surface
Installation:
Vertical Type
Step:
Double-Step
The reducer is generally used for low-speed and high-torque transmission equipment. The motor, internal combustion engine or other high-speed running power is used to achieve the purpose of deceleration by meshing with the large gear on the output shaft through a gear with a small number of teeth on the input shaft of the reducer. The reducer will also have several pairs of gears with the same principle to achieve the ideal reduction effect. The ratio of the number of teeth of the large and small gears is the transmission ratio.
| SPECIFICATIONS | STAGE | RATIO | RATED TORQUE (N.m) | ||
| PLF42-42mm Planetry Gear Reducer | L1 | 4 | 9 | ||
| 5 | 9 | ||||
| 7 | 5 | ||||
| 10 | 5 | ||||
| L2 | 16 | 12 | |||
| 20 | 12 | ||||
| 25 | 10 | ||||
| 28 | 10 | ||||
| 35 | 10 | ||||
| 40 | 10 | ||||
| 50 | 10 | ||||
| 70 | 10 | ||||
| Adapted motor | ∅5-10/ ∅22-2/F31-M3 | ||||
| Rated Input Speed (rpm) | 3000/min | ||||
| Max Input Speed (rpm) | 6000/min | ||||
| Backlash | L1 | ≤15 Arcmin | |||
| L2 | ≤10 Arcmin | ||||
| Fault stop torque(N.m) | 2 times of rated torque | ||||
| Efficiency | L1 | 96% | |||
| L2 | 94% | ||||
| Average life span | 20000h | ||||
| Operating temperature | -10°~+90° | ||||
| Nosie | ≤60 db | ||||
| Weight (kg) | L1 | 0.25 | |||
| L2 | 0.35 | ||||
| IP | 54 | ||||
| Installation method | Any installation method | ||||
