Model NO.
NMRV025
Speed Ratio
50
Housing Material
Aluminium Alloy
Worm Gear Material
Chromium Alloy 20cr
Worm Wheel Material
Bronze Zqsn10-1
Input Speed
1400rpm
Output Speed
28rpm
Output Torque
12n.M
Color
Blue / Silver
Package Size
80*82*100mm
Package Weight
1kg
Material
Aluminium Alloy
Manipulate Way
Robotics
Manufacturing Method
Cut Gear
Changes Way
Stepped
Transport Package
Carton
Specification
ISO9001: 2008
Trademark
chenxin
Origin
China Zhejian
HS Code
8483409090
Production Capacity
30000 Set/Month
Application:
Industry
Hardness:
Hardened
Type:
Worm and Wormwheel
Taizhou Sihai Machinery Co., Ltd.has been specialising in the manufacture and export of RV series worm gearboxes and other power transmission products for years, dedicated to provide to our customers good quality products in competitive prices. The main products are RV series worm gear speed reducers, UD series mechanical speed variators, G3 series helical geared motors and the specially designed reducers for polishing machines. Our products are widely used in the mechanical apparatus for foodstuff, ceramics, package, chemical, printing, and plastics, etc.
| Motor power | Model | speed ratio | output speed | output toruqe |
| 0.06kw 1400rpm | NMRV025 | 5 | 280rpm | 1.8N.M |
| NMRV025 | 7.5 | 186rpm | 2.6N.M | |
| NMRV025 | 10 | 140rpm | 3.4N.M | |
| NMRV025 | 15 | 94rpm | 4.9N.M | |
| NMRV025 | 20 | 70rpm | 6.1N.M | |
| NMRV025 | 25 | 56rpm | 7.5N.M | |
| NMRV025 | 30 | 47rpm | 8.2N.M | |
| NMRV025 | 40 | 35rpm | 10.2N.M | |
| NMRV025 | 50 | 28rpm | 12.0N.M | |
| NMRV025 | 60 | 24rpm | 14.0N.M | |
| 0.09kw 1400rpm | NMRV025 | 5 | 280rpm | 2.7N.M |
| NMRV025 | 7.5 | 186rpm | 3.9N.M | |
| NMRV025 | 10 | 140rpm | 5.1N.M | |
| NMRV025 | 15 | 94rpm | 7.3N.M | |
| NMRV025 | 20 | 70rpm | 9.3N.M | |
| NMRV025 | 25 | 56rpm | 11.0N.M | |
| NMRV025 | 30 | 47rpm | 13.0N.M | |
| NMRV025 | 40 | 35rpm | 16.0N.M |
