Udl Speed Variator Variable Reducer Coaxial Stepless Motor Gearbox Diecast Aluminium Alloy Silent Vibration-Free Running Stable Manufacture Udl Speed Variator, Udl Speed Variator, Udl

Product detail

Model NO.

UDL Speed Variator-YY

Worm Gear Box

Transport Package

Wooden Box

Trademark

no brand

Origin

China

HS Code

848390009

Application:

Motor, Electric Cars, Motorcycle, Machinery, Marine, Toy, Agricultural Machinery, Car

Function:

Distribution Power, Clutch, Change Drive Torque, Change Drive Direction, Speed Changing, Speed Reduction, Speed Increase

Layout:

Three-Ring

Hardness:

Hardened Tooth Surface

Installation:

Torque Arm Type

Step:

Stepless

UDL Speed Variator Variable Reducer Coaxial Stepless Motor Gearbox Diecast Aluminium Alloy Silent Vibration-free Running Stable Manufacture UDL Speed Variator

UDL Series planetary cone & disk step-less speed variator

high quality and low price
pls feel free to contact with us if you have any problem

Variator and speed motorvariator

For power ratings from 0,15 to 9,2 kW.
Silent, vibration-free running.
High efficiency.
Bidirectional rotation.
Control handwhel positional on either side.
Speed repeatability at max: ± 0,5%
Speed repeatability at min: ± 0,1%.
Regulaton sensibility: 0,5 rpm.
Casings (TX): diecast aluminium alloy.
Shafts: case hardened and tempered 20Cr steel after ground >HRC60

Internal components: 100Cr6 heat-treated steel.

All the sizes are painted with Ral 5010 blue epoxy-polyester powder.
Variator and speed motorvariator.

For power ratings from 0,15 to 9,2 kW.
Silent, vibration-free running.
High efficiency.
Bidirectional rotation.
Control handwhel positional on either side.
Speed repeatability at max: 0,5%
Speed repeatability at min: 0,1%.
Regulaton sensibility: 0,5 rpm.
Casings (TX): diecast aluminium alloy.
Shafts: case hardened and tempered 20Cr steel after ground >HRC60

Internal components: 100Cr6 heat-treated steel.

All the sizes are painted with Ral 5010 blue epoxy-polyester powder.

Udl Speed Variator Variable Reducer Coaxial Stepless Motor Gearbox Diecast Aluminium Alloy Silent Vibration-Free Running Stable Manufacture Udl Speed Variator
