Application
Motor, Machinery, Robotics, Automation and Robotic Technologies
Function
Speed Changing, Speed Reduction
Layout
Helical
Hardness
Hardened Tooth Surface
Installation
Vertical Type
Step
Single-Step
Type
Planetary Gear Box
Output Shaft Dia.
6-14mm
Maxium Output Torque
3 Times Than The Rated Output Torque
Rated Input Speed
3000
Backlash
L1< 5 Arc. L2<8 Arc.
Torsional Rigidal Force
7 Nm / Arcmin
Allowable Axial Force
765 N
Allowable Radial Force
1530 N
Service Life
10000 Hr
Efficiency
>97%
Weight
1.5kgs
Trademark
WANSHSIN
Transport Package
1PC / Paper Carton
Specification
Ratio: 1: 3 - 1: 200
Origin
China
HS Code
8483402000
WANSHSIN planetary reducers,Gearbox,planetary gearbox
Model name
W-AB-060-010-K-P2-I1-01
1.Wanshsin mark
2.AB:Square flange
AB:Precise helical-square flange
3.Box.No.:060,090,120,150,180,220
4.Ratio:3,4,5,7,10...100
5.K:Output shaft is with key
S:Output shaft is smooth solid shaft
6.Back lash:P1>precision P2>standard
7.Motor mark(pls check motor mark chart for details)
8.Output mark(pls check flange mark for details)
Internal structure
Performance table
Product Pictures:
