Model NO.
kmm1318I
Brake Size
420X200
PCD335
Cbd221/281
Bearing
518445 518445
Quality
Good
Transport Package
by Sea
Specification
KMM1318R
Trademark
JLB
Origin
China
Production Capacity
50000PCS/Month
Condition:
New
Axle Number:
1
Application:
Truck
Certification:
ASTM
Material:
Steel
Type:
Rear Axles
| American inboard axle | ||||||||||||
| AXLE TYPE | BRAKE SIZE | WHEEL FIXING | NO.XSIZE OF WHEEL STUD (DIM A) | WHEEL REG.DIA.(DIM B) | DIM D | BEARING | WHEEL RIM SIZE | BEAM SIZE | AXLE CAPACITY | SPRING SEAT INSTALLATION | TRACK LENGTH(DIM C) | WEIGHT |
| KMMR1318B | 420*180 | ISO | 10*M22*335 | 281 | 725 | 518445 518445 | 20´´ | 127*19 | 13T | ≤450 | 1840mm | 378KG |
| KMMR1320B | 420*200 | ISO | 10*M22*335 | 281 | 735 | 518445 518445 | 20´´ | 127*19 | 13T | ≤450 | 1840mm | 390KG |
| KMMR1318C | 420*180 | ISO | 10*M22*285.75 | 221 | 725 | 518445 518445 | 20´´ | 127*19 | 13T | ≤450 | 1840mm | 378KG |
| KMMR1320C | 420*200 | ISO | 10*M22*285.75 | 221 | 735 | 518445 518445 | 20´´ | 127*19 | 13T | ≤450 | 1840mm | 390KG |
| KMMR1318A | 420*180 | JAP | 8*M20*285 | 221 | 725 | 518445 518445 | 20´´ | 127*19 | 13T | ≤450 | 1840mm | 378KG |
| KMMR1622E | 420*220 | ISO | 10*M20*335 | 281 | 738 | 518445 220149 | 20´´ | 127*25 | 16T | ≤450 | 1850mm | 440KG |
| KMM1318B | 420*180 | ISO | 10*M22*335 | 281 | 725 | 518445 518445 | 20´´ | SQUARE150 | 13T | ≤450 | 1840mm | 378KG |
| KMM1320B | 420*200 | ISO | 10*M22*335 | 281 | 735 | 518445 518445 | 20´´ | SQUARE150 | 13T | ≤450 | 1840mm | 390KG |
| KMM1318C | 420*180 | ISO | 10*M22*285.75 | 221 | 725 | 518445 518445 | 20´´ | SQUARE150 | 13T | ≤450 | 1840mm | 378KG |
| KMM1320C | 420*200 | ISO | 10*M22*285.75 | 221 | 735 | 518445 518445 | 20´´ | SQUARE150 | 13T | ≤450 | 1840mm | 390KG |
| KMM1318A | 420*180 | JAP | 8*M20*285 | 221 | 725 | 518445 518445 | 20´´ | SQUARE150 | 13T | ≤450 | 1840mm | 378KG |
| KMM1622E | 420*220 | ISO | 10*M20*335 | 281 | 738 | 518445 220149 | 20´´ | SQUARE150 | 16T | ≤450 | 1850mm | 440KG |
