Model NO.
160C
Applicable
PE, PP, PVDF
Power Supply
220V 50Hz, 1pH
Heating Plate
1.5kw
Temperature Deviation
±5ºC
Overall Power
2.9kw
Planing Tool
1.4kw
Max Temperature
270ºC
Transport Package
1PCS Plywood Case
Specification
63-75-90-110-125-140-160mm
Trademark
Welping
Origin
China
HS Code
8515809090
Production Capacity
5000pieces/Year
Welding Range:
160mm
Cooling Way:
Air Cooling
Control:
Manual
Frequency Range:
Intermediate Frequency
Electric Current:
AC
Type:
Resistance Butt Welder
| Model | WP160C | ||
| Suitable materials | PE, PP, PVDF | ||
| Welding range (mm) | 63-160 | ||
| Standard reducers (mm) | 63-75-90-110-125-140-160 | ||
| Power supply | 220V/50Hz, 1PH | ||
| Total power | 2.5 KW | ||
| Heating plate | 1.5 KW | ||
| Planing tool | 1.0 KW | ||
| MaxTemperature of heating plate | 270ºC | ||
| Temperature Deviation | ±5ºC | ||
| Total Weight | 62kg | ||
| Net weight | 50kg | ||
| Basic Frame | plywood | 700*490*600mm | |
Basic frame
Featured by
· Italy DNP quick coupler
· Chromated hydraulic cylinder made
of 1045(ASTM)/S45(JIS)/C45(DIN) steel
· Chromated integral shaft made
of1045(ASTM)/S45C(JIS)/C45(DIN) steel
· Base made of Q235 steel with spraying treatment
· Cast aluminum clamps, sandblasting & Spraying
treatment
Featured by
· Italy DNP quick coupler
· Chromated hydraulic cylinder made
of 1045(ASTM)/S45(JIS)/C45(DIN) steel
· Chromated integral shaft made
of1045(ASTM)/S45C(JIS)/C45(DIN) steel
· Base made of Q235 steel with spraying treatment
· Cast aluminum clamps, sandblasting & Spraying
treatment
Planing tool
Featured by
Featured by
- HSS blade with double edge
- Die-cast aluminum trimmer plate, durable and anti-corrosion
- Aluminum alloy frame of motor with good heat dissipation performance
- Carbon brush motor with pure copper wire
Heating plate
Heating plate with high quality PTFE coating, enables swift
temperature control.
| SN | Model | Welding range | Power supply |
| 1 | WP160C | 63-75-90-110-125-140-160 (mm) | 220V, 50Hz |
| 2 | WP200C | 63-75-90-110-125-140-160-180-200 (mm) | 220V, 50Hz |
| 3 | WP250C | 90-110-125-140-160-180-200-225-250 (mm) | 220V, 50Hz |
