250-500mm Hydraulic Automatic Poly Hydraulic Butt Fusion Plastic PE Pipe Hot Melt Butt Welding Machine HDPE Pipe Welder, Butt Welder Machine, Plastic Butt Welder

Supplier Hangzhou Welping Machinery Equipment Co., Ltd.
Price $2400.00 / Pieces
Availability In Stock
Mini Order:
+-
Subtotal: $2400

Purchase details

Payments:

Tax:

Tax Included

Returns&Refunds:

Eligible for refunds within 30 days of receiving products. returns and refunds

Model NO.
WP500A
Max Temperature
270ºC
Size
250-315-355-400-450-500 (mm)
Power Supply
380V 50Hz, 3pH
Overall Power
9.1kw
Heating Plate
6.5kw
Planing Tool
1.1kw
Hydraulic Station
1.5kw
Pressure Adjusting
0-8.0MPa
Temperature Deviation
±7ºC
Transport Package
3 PCS Plywood Case
Specification
1330*790*860mm 860*610*1020mm 670*570*660mm
Trademark
Welping
Origin
China
HS Code
8515809090
Production Capacity
6000pieces/Year
Cooling Way:
Air Cooling
Control:
Semi-Automatic
Frequency Range:
Intermediate Frequency
Electric Current:
AC
Type:
Resistance Butt Welder
Applicable:
PE, PP, PVDF

250-500mm Hydraulic Automatic Poly Hydraulic Butt Fusion Plastic PE Pipe Hot Melt Butt Welding Machine HDPE Pipe Welder

ModelWP500A
Suitable materialsPE, PP, PVDF
Range250-280-315-355-400-450-500mm
Power supply380V, 3PH
Frequency50 Hz
Total power9.1 KW
         Heating plate6.5 KW
         Planing tool1.1KW
         Hydraulic station1.5 KW
Max.Pressure8MPa
Hydraulic oilL-HM46
Max.Temperature of heating plate 270ºC
Temp.Deviation in Surface±7ºC
Total Weight406kg
Net weight346kg
Basic Frameplywood1330*790*860mm
Hydraulic Unitplywood670*570*660mm
Planing tool & heating plateplywood860*610*1020mm
250-500mm Hydraulic Automatic Poly Hydraulic Butt Fusion Plastic PE Pipe Hot Melt Butt Welding Machine HDPE Pipe Welder250-500mm Hydraulic Automatic Poly Hydraulic Butt Fusion Plastic PE Pipe Hot Melt Butt Welding Machine HDPE Pipe Welder250-500mm Hydraulic Automatic Poly Hydraulic Butt Fusion Plastic PE Pipe Hot Melt Butt Welding Machine HDPE Pipe Welder250-500mm Hydraulic Automatic Poly Hydraulic Butt Fusion Plastic PE Pipe Hot Melt Butt Welding Machine HDPE Pipe Welder250-500mm Hydraulic Automatic Poly Hydraulic Butt Fusion Plastic PE Pipe Hot Melt Butt Welding Machine HDPE Pipe Welder
250-500mm Hydraulic Automatic Poly Hydraulic Butt Fusion Plastic PE Pipe Hot Melt Butt Welding Machine HDPE Pipe Welder
250-500mm Hydraulic Automatic Poly Hydraulic Butt Fusion Plastic PE Pipe Hot Melt Butt Welding Machine HDPE Pipe Welder

250-500mm Hydraulic Automatic Poly Hydraulic Butt Fusion Plastic PE Pipe Hot Melt Butt Welding Machine HDPE Pipe Welder
250-500mm Hydraulic Automatic Poly Hydraulic Butt Fusion Plastic PE Pipe Hot Melt Butt Welding Machine HDPE Pipe Welder
250-500mm Hydraulic Automatic Poly Hydraulic Butt Fusion Plastic PE Pipe Hot Melt Butt Welding Machine HDPE Pipe Welder
250-500mm Hydraulic Automatic Poly Hydraulic Butt Fusion Plastic PE Pipe Hot Melt Butt Welding Machine HDPE Pipe Welder250-500mm Hydraulic Automatic Poly Hydraulic Butt Fusion Plastic PE Pipe Hot Melt Butt Welding Machine HDPE Pipe Welder
250-500mm Hydraulic Automatic Poly Hydraulic Butt Fusion Plastic PE Pipe Hot Melt Butt Welding Machine HDPE Pipe Welder
SNModelPipe rangePower supplyRemarks
1WP160A63-75-90-110-125-140-160 (mm)220V, 50Hz
2WP200A63-75-90-110-125-140-160-180-200(mm)220V, 50Hz
3WP250A90-110-125-140-160-180-200-225-250(mm)220V, 50Hz
4WP315A110-125-140-160-180-200-225-250-280-315 (mm)220V, 50Hz
5WP355A160-180-200-225-250-280-315-355 (mm)220V/380V,50Hz
6WP400A180-200-225-250-280-315-355-400 (mm)380V, 50Hz
7WP450A180-200-225-250-280-315-355-400-450 (mm)380V, 50Hz
8WP500A250-280-315-355-400-450-500 (mm)380V, 50Hz
9WP630A315-355-400-450-500-560-630 (mm)380V, 50Hz
10WP800A630-710-800 (mm)380V, 50Hz
11WP1000A800-900-1000 (mm)380V, 50Hz
12WP1200A1000-1100-1200(mm)380V, 50Hz
13WP1400A10001200-1400(mm)380V, 50Hz
14WP1600A1200-1400-1600 (mm)380V, 50Hzcustomized
15WP2000A1600-1800-2000(mm)380V, 50Hzcustomized
16WP2500A2200-2500 (mm)380V, 50Hzcustomized
17WP3000A3000 (mm)380V, 50Hzcustomized
250-500mm Hydraulic Automatic Poly Hydraulic Butt Fusion Plastic PE Pipe Hot Melt Butt Welding Machine HDPE Pipe Welder250-500mm Hydraulic Automatic Poly Hydraulic Butt Fusion Plastic PE Pipe Hot Melt Butt Welding Machine HDPE Pipe Welder250-500mm Hydraulic Automatic Poly Hydraulic Butt Fusion Plastic PE Pipe Hot Melt Butt Welding Machine HDPE Pipe Welder250-500mm Hydraulic Automatic Poly Hydraulic Butt Fusion Plastic PE Pipe Hot Melt Butt Welding Machine HDPE Pipe Welder
250-500mm Hydraulic Automatic Poly Hydraulic Butt Fusion Plastic PE Pipe Hot Melt Butt Welding Machine HDPE Pipe Welder
250-500mm Hydraulic Automatic Poly Hydraulic Butt Fusion Plastic PE Pipe Hot Melt Butt Welding Machine HDPE Pipe Welder
