Automatic Motor Armature Commutator Welder
Quick Detail:
1. Model No.:ND-TMI-7
2. This machine is used for commutator hook welding.
3. It can automatically indexing and welding, operator only needs to load and unload armature,
3. Commutator ranges from 8~70mm.
4. It can be used for different armatures by changing tooling.
5. Easy operation and adjustment.
Description:
This commutator welder is used for fusing commutator bar. Stator loading and unloading shoud be done by manual, Machine will do welding and indexing automatically. This welder is equipped with Miyachi power source so that it can ensure the stable performance.
Technical parameter:
| Wire diameter range: | 0.15~1.2 mm |
| Armature OD: | 20~80 mm |
| Stack length: | 10~90 mm |
| Armature Slot: | Even slot |
| Turn number: | 0~9999 |
| Commutator diameter: | 8~40 mm |
| Air supply pressure: | 4~6 Kg/cm2 |
| The machine total power: | 5KW |
| Voltage: | Three phase AC 380V 50/60 Hz |
| Weight: | 1050 Kg |
| Dimension: | 2000X1650X1950mm |
Competitive advantages:
It can be used for different armatures by changing tooling. Easy operation and adjustment.
With good service, unique philosophy, professional team and reliable quality, we win the worldwide customers' confidence gradually. We directly and indirectly supply our products to more than 50 countries .
| Customerized service | 1. Customized product design and manufacturing |
| 2. Customized tranning |
| 3.Technical suggestions |
| After-sales service | 1. Warranty Period: 12 month usually |
| 2. Overseas service center available |
3. Engineers available to service overseas |
NIDE is a company devoted in the field of electric motors manufacturing, providing one-stop service for its customers.
NIDE has three main business divisions.
The first division is to provide different kinds of motor manufacturing machines, it is our Main business, including stand along machine, fully-auto complete line for armature and stator production, and the motor assembly line.
The second division is to supply the full range of motor components such as commutator, ball bearing, carbon brush, insulation paper, shaft, magnet, fan, motor cover, etc.
The third division is to provide technical support and consulting, project support and turn-key service for some motor manufacturing.
