Model NO.
WP355A
Style
Vertical
Packing
2 PCS
Transport Package
Plywood Case
Specification
hydraulic driving
Trademark
Welping
Origin
China
HS Code
8515809090
Production Capacity
20000 Pieces/Year
Welding Range:
110-355mm
Cooling Way:
Air Cooling
Control:
Semi-Automatic
Frequency Range:
Low Frequency
Electric Current:
AC
Type:
Resistance Butt Welder
.·WELPING had been focusing on thermoplastic welding equipment developing, manufacturing and selling since
2005
·Self-managing Integrated production equipment & procedures: die casting, metal fabrication and process, powder coating etc.
·New modern workshop, 20000m2, up to date processing equipment: 12kw laser cutting and welding, 800,
1200 tons die casting molding machinery, CNC etc.
Technical parameters
| Model | WP355A | |
| Suitable materials | PE, PP, PVDF | |
| Range | 160-180-200-250-280-315-355mm | |
| Power supply | 220V | |
| Frequency | 50 Hz | |
| Total power | 5.3 KW | |
| Heating plate | 3.55 KW | |
| Planing tool | 1.0KW | |
| Hydraulic station | 0.75 KW | |
| Max.Pressure | 16MPa | |
| Hydraulic oil | L-HM46 | |
| Max.Temperature of heating plate | 270ºC | |
| Temp.Deviation in Surface | ±7ºC | |
| Total Weight | 260kg | |
| Net weight | 225kg | |
| Basic Frame | plywood | 1030*610*700mm |
| Hydraulic Unit&Planing tool & heating plate | plywood | 680*670*910mm |
Selection chart for hydraulic butt welding machine
| SN | Model | Pipe range | Power supply | Notes |
| 1 | WP160A | 63-75-90-110-125-140-160 (mm) | 220V, 50Hz | |
| 2 | WP200A | 63-75-90-110-125-140-160-180-200 (mm) | 220V, 50Hz | |
| 3 | WP250A | 90-110-125-140-160-180-200-225-250 (mm) | 220V, 50Hz | |
| 4 | WP315A | 110-125-140-160-180-200-225-250-280-315 (mm) | 220V, 50Hz | |
| 5 | WP355A | 160-180-200-225-250-280-315-355 (mm) | 380V, 50Hz | |
| 6 | WP400A | 160-180-200-225-250-280-315-355-400 (mm) | 380V, 50Hz | |
| 7 | WP450A | 200-225-250-280-315-355-400-450 (mm) | 380V, 50Hz | |
| 8 | WP500A | 250-280-315-355-400-450-500 (mm) | 380V, 50Hz | |
| 9 | WP630A | 315-355-400-450-500-560-630 (mm) | 380V, 50Hz | |
| 10 | WP800A | 630-710-800 (mm) | 380V, 50Hz | |
| 11 | WP1000A | 800-900-1000 (mm) | 380V, 50Hz | |
| 12 | WP1200A | 1000-1100-1200(mm) | 380V, 50Hz | |
| 13 | WP1600A | 1200-1400-1600 (mm) | 380V, 50Hz | customized |
| 14 | WP2000A | 1600-1800-2000(mm) | 380V, 50Hz | customized |
| 15 | WP2500A | 2200-2500 (mm) | 380V, 50Hz | customized |
| 16 | WP3000A | 3000 (mm) | 380V, 50Hz | customized |
Basic frame
Featured by
· Italy DNP quick coupler
· Chromated hydraulic cylinder made
of 1045(ASTM)/S45(JIS)/C45(DIN) steel
· Chromated integral shaft made
of1045(ASTM)/S45C(JIS)/C45(DIN) steel
· Cast aluminum clamps with sandblasting &
spraying treatment
Featured by
· Italy DNP quick coupler
· Chromated hydraulic cylinder made
of 1045(ASTM)/S45(JIS)/C45(DIN) steel
· Chromated integral shaft made
of1045(ASTM)/S45C(JIS)/C45(DIN) steel
· Cast aluminum clamps with sandblasting &
spraying treatment
Planing tool
Featured by
Featured by
- HSS blade with double edge
- Die-cast aluminum trimmer plate, durable and anti-corrosion
- Full gears transmission, more efficient, more steady
- Aluminum alloy frame of the motor with good heat dissipation performance
- Asynchronous motor with gearbox
Hydraulic station
Featured by
Featured by
- Fully enclosed housing with vents can prevent dust and dirt from entering
- 380V asynchronous motor
- CHNT electricity leakage protection switch
- Data logger(optional)
- 500V/100A electric meter
- Ø100mm pressure meter
- Relief valve, regulating valve, maintaining valve
Heating plate
Featured by
Featured by
- Bakelite handle with high insulating property and thermal insulation
- Thermocouple temperature sensor
- Heating element
- Aviation plug
General Terms
1. PAYMENT
We accept a 30% TT deposit and 70% balance payment against photo before delivery or 100% TT in advance.
2. LEAD TIME
Standard items and light-OEM items, WELPING can finish in around 10-15 days.
3. WARRANTY
18 Months from delivery we take full responsibility for parts with quality problems and provide them for free requirements
4. CUSTOMIZED DESIGN
Our experienced technical team can develop different solutions according to customers. MOQ is required for special requirements.
5. ABOUT AGENCY BUSSINESS
Welcome customers with sincerity and influence to discuss cooperation matters with us
