Model NO.
GN-330A
Welding Current
0-99A
Welding Thickness
0.03 - 0.25mm
Weight
45kg
Warrenty
1 Year
Product Dimensions
30.5cm(L) X 50.5cm(W) X 49cm(H)
Support
One- Stop Service and Turn-Key Project
Operation Temperature
-20 - 40ºC
Transport Package
Standard Exporting Package
Trademark
Gelon
Origin
Shandong China
Production Capacity
200set/Month
Control:
Automatic
Type:
Spot Welders
Condition:
New
Input Voltage:
220V/50Hz
Air Pressure Range:
0.1 - 0.8 MPa
Powder:
10kw
Application
GN-330A Precise Pneumatic Single Point Welding Machine is specifically designed for professional Li-ion Battery Research. It is
mainly used for welding the cylinder core's negative terminal (Nickel tab) to the bottom of the cylinder case. A Diameter 2mm x
180mm length welding needle is easily inserted into the cylinder case to weld at the bottom. This machine is controlled by the
microcontroller, which is very easy to operate and can provide stable performance.
mainly used for welding the cylinder core's negative terminal (Nickel tab) to the bottom of the cylinder case. A Diameter 2mm x
180mm length welding needle is easily inserted into the cylinder case to weld at the bottom. This machine is controlled by the
microcontroller, which is very easy to operate and can provide stable performance.
| Power Supply | 220-240V, Single Phase 50/60Hz |
| Max. Power | 10KW |
| Air Pressure Range | 0.1 - 0.8 MPa ( air compressor is required, pls order at related product below ) |
| Welding Current | 0-99A |
| Welding Thickness | 0.03 - 0.25mm |
| Operation Temperature | -20 - 40ºC |
| Controller | Controlled by microcontroller,achieve monopulse, dipulse, mutiple-pulse welding |
| Pressure | Pressure applied on the welding needle can be adjusted independently and easy to operate |
| Design | Unique Photoelectric switch design Good appearance, small size and light weight Welding spot looks beautiful,free spark, stable welding current |
| Weight | 45 kg (100 lbs) |
| Product Dimensions | 30.5cm(L) x 50.5cm(W) x 49cm(H) |
| Warranty | one year limited with lifetime support |
1 Standard exported package : Internal anticollision protection, external export wooden box packaging.
2 Shipping by Fedex, by air, by sea according to customers' requirements to find the most suitable way,
Company
We can supply one stop solution ( turn key project) for you.
1. Full set of lithium battery materials, including:
LiMn2O4, LTO, LiNiMnCoO2(NMC), LiCoO2, Graphite(MCMB)and other cathode&anode battery materials; Aluminum foil, copper foils, battery separator, etc.
2. Full set of lithium battery equipments, for example:
Mixing machine --coating machine--oven--rolling machine--welding machine--slitting / cutiing machine --winding machine--sealed machine, etc.
3. Full set of lithium battery technology.
We can design the laboratory and production line, according to customer's request.
