Model NO.
KTG-30
Max Loadimg Weight
30 T
Adjustable Mode
Screw Adjustable Welding Rotator
Wheel Quantity
4 Wheels
Wheel Material
Rubber or Steel,or Both
Suitable Diameter of Tank
500-4200mm
Steel Wheel Diameter
340mm
Steel Wheel Width
300mm
Linear Speed
6-60m/H
Power
1.1 Kw
Warranty
1 Year
Color
Customized
Input Voltagge
380-600V
Used for
Pipe Tank Welding Rotator
Lead Time
20 Days
Transport Package
Standard
Trademark
Lemar
Origin
Wuxi, China
HS Code
8428909090
Type:
Welding Turning Rolls
Structure:
Gantry
Welding Turning Rolls Type:
Self-Adjusting
Welding Tilter Type:
Flexible Combination
Condition:
New
Model:
Ktg-30
30T Thread adjustable Pipe welding rotator Tank turning rolls
Welding turning rolls pipe welding Rotator is a welding auxiliary equipment widely used in industries such as wind power, pressure vessels, petrochemicals, pipelines, steel structures, boilers, shipbuilding, pile welding repair and other industries.
By using you can reduces the fatigue of workers and provides a safe method to locate cylindrical parts.
Our pipe rotation welding rollers has many sizes and weight capabilities, which can adapt to your application.
Specifications:
The welding turning roller can be one drive with one idler, one drive with two idlers, or one drive with three idlers, according to the actual needs of customers.
Faults and solutions that are prone to occur during the use of the welding roller rotator:
30 -ton adjustable roller rotator characteristics:
1. It can be arbitrarily combined according to the weight and length of the welding parts, which is convenient and flexible;
2. Automatically adjust the center of the roller within the specified range, apply welding parts of different diameter, and stable in the welding of the cylindrical welding;
3. Power -powered DC motor driver, speed adjustment, large welding range, stable speed;
Welding turning rolls pipe welding Rotator is a welding auxiliary equipment widely used in industries such as wind power, pressure vessels, petrochemicals, pipelines, steel structures, boilers, shipbuilding, pile welding repair and other industries.
By using you can reduces the fatigue of workers and provides a safe method to locate cylindrical parts.
Our pipe rotation welding rollers has many sizes and weight capabilities, which can adapt to your application.
Specifications:
| Model | Max loading weight(kg) | Suitable work range(mm) | Rubber wheel diameter and width(mm) | Metal wheel diameter and width(mm) | Roller linear speed(m/h) | Power | Distance Adjustment method |
| KTG-2 | 2000 | 200-1200 | Ф200*100 | 2*Ф190*16 | 6-60 | 2*0.18 | Manual/screw adjustable |
| KTG-5 | 5000 | 250-2300 | Ф250*100 | 2*Ф240*20 | 2*0.37 | ||
| KTG-10 | 10000 | 300-2800 | Ф300*120 | 2*Ф290*25 | 2*0.55 | ||
| KTG-20 | 20000 | 500-3500 | Ф350*120 | 2*Ф340*35 | 2*1.1 | ||
| KTG-30 | 30000 | 600-4200 | Ф400*120 | 2*Ф390*45 | 2*1.5 | ||
| KTG-60 | 60000 | 750-4800 | Ф450*120 | 2*Ф440*60 | 2*2.2 | Screw/lead adjustable | |
| KTG-80 | 80000 | 850-5000 | Ф500*120 | 2*Ф490*70 | 2*3 | ||
| KTG-100 | 100000 | 1000-5500 | Ф500*120 | 2*Ф490*80 | 2*3 | ||
| KTG-150 | 150000 | 1100-6000 | / | Ф620*220 | 2*4 | ||
| KTG-250 | 250000 | 1100-7500 | / | Ф660*260 | 2*5.5 | ||
| KTG-400 | 400000 | 1100-7500 | / | Ф750*320 | 2*7.5 | ||
| KTG-500 | 500000 | 1100-7500 | / | Ф750*400 | 2*11 | ||
| Speed regulation mode -- frequency conversion stepless speed regulation or DC stepless speed regulation | |||||||
The welding turning roller can be one drive with one idler, one drive with two idlers, or one drive with three idlers, according to the actual needs of customers.
Faults and solutions that are prone to occur during the use of the welding roller rotator:
| No. | Phenomenon | Reasons | Measures |
| 1 | The motor does not turn and the indicator light does not light up | The three-phase voltage is not connected to the control box (or external problems) | Check for external factors |
| 2 | The motor does not turn, the indicator light is on | 1. Inverter overload protection 2. Motor damage | 1. Manually reset the inverter 2. Replace the motor |
| 3 | Offset to one side when the workpiece is turned | The drive/idler roller frame is not on the same plane, or the center diagonal of the master-slave roller frame is not corrected | Check the flatness and correct the center diagonal of the master-slave roller frame |
30 -ton adjustable roller rotator characteristics:
1. It can be arbitrarily combined according to the weight and length of the welding parts, which is convenient and flexible;
2. Automatically adjust the center of the roller within the specified range, apply welding parts of different diameter, and stable in the welding of the cylindrical welding;
3. Power -powered DC motor driver, speed adjustment, large welding range, stable speed;
