Model NO.
SUD315H
Name
HDPE Pipe Butt Welding Machine/Butt Fusion Jointin
Fusion Range(mm)
90 110 125 140 160 180 200 225 250 280 315
Welding Material
PE PP PPR PVDF
Package(mm)
2 Wooden Boxes
Basic Frame
740*810*710
Weight
230kg
Cub
0.83cbm
Total Power
5.35kw/220V
Heater Power
3.5kw/220V
Trimmer Power
1.1kw/220V
Hydraulic Unit Power
0.75kw
Transport Package
Standard Export Wooden Box
Specification
ISO, CE, SGS
Trademark
Suda
Origin
China(Mainland)
HS Code
8515290000
Production Capacity
100sets/Months
Welding Range:
315mm
Cooling Way:
Air Cooling
Control:
Semi-Automatic
Frequency Range:
Low Frequency
Electric Current:
AC
Type:
Butt Welders
90-315mm HDPE Pipe Butt Welding Machine/Butt Fusion Jointing Machine
Suitable for welding of plastic pipes and fittings made from PE, PP&PVDF.
Be made of Aluminum material.
Consists of Planning Tool, Heating Plate, Basic Frame, Hydraulic Unit and Support.
Removerable PTFE coated heating plate with seperate temperature control system.
Electric Planning Tool with reversible double cutting edge blades.
Hydraulic Unit provides welding machine with compressing power.
Be made of Aluminum material.
Low starting pressure ensures reliable welding quality of small pipes.
Temperature Controller and Timer, easy to know the exact time and temperature.
=====Specification=====
| Model | SUD315H |
| Welding range(mm) | 90 110 125 140 160 180 200 225 250 280 315 |
| Heating Plate Max. Temp | 270°C |
| Temp. Deviation in Surface | ≤±5°C |
| Working Voltage | 220V/50HZ |
| Pressure Adjustable Ranges | 0-6.3MPa |
| Heating Plate Power | 3.60KW |
| Planning Tool Power | 1.10KW |
| Hydraulic Unit Power | 0.75KW |
| Total Power | 5.35KW |
| Weight | 230KG |
| Volume | 1.0M3 |
=====Pictures=====
======Machine Include=====
=====We have enough stock=====
=======Application======
======Packing and Loading =====
