Model NO.
SDF1200
Name
90 Degree 45 Degree Elbow Tee Cross HDPE Fittings
Warranty
1 Year
Working Voltage
380V 50Hz
Total Power
76.4kw
Weight
18000kg
Current
AC
Process Applicable Materials
PE PP PVDF
Application
Fabricating Elbow, Tee, Y Shape Fittings
Package
11 Wooden Boxes
Volume
45.93cbm
Transport Package
Wooden Box or Strich Film
Specification
ISO, CE, SGS
Trademark
SUDA
Origin
China
HS Code
85152900
Production Capacity
2sets/Month
Welding Range:
630 710 800 900 1000 1100 1200
Cooling Way:
Air Cooling
Control:
Automatic
Frequency Range:
Low Frequency
Electric Current:
AC
Type:
Butt Welders
SUDA PLASTIC PIPE MACHINERY CO.,LTD. Is a professional manufacturer in China. Years of experience in producing and research, we can supply the best quality machines to all the customers.
Our products including: Hydraulic Butt Fusion Machines, Manual Butt Fusion Machines, Workshop Fitting Machines, Workshop Cutting Machines, Electrofusion Machine, HDPE Fittings, Electrofusion Fittings, Plastic Sheet Butt Welding/Rolling/Bending Machines Etc.
Customers' biggest benefit is our goal, machine's quality is the life of our company. Many years of growth, we have our best partners in the world.
We have the certificate of ISO and CE approval. This ensures our machines have the highest quality, best service and reliable warranty.
We have the concept of "Customers First, Quality Foremost", we sincerely welcome all friends visit and co-operation.
====>>Products Details
630-1200mm 90 Degree 45 Degree Elbow Tee Cross HDPE Fittings Fabrication Welding Machine
- Suitable for fabricating ELBOW, Tee,Cross, Y shape(45º and 60º) fitting of PE PP PVDF in workshop.
- Integrated structure, nothing remains but to choose the different special clamps while fabricating different fittings.
- Consist of Basic Frame, Hydraulic Unit, Trimmer, Heater and Electric Control Unit.
- Removable PTEE coated heating plate with seperature temperature control system.
- Electric Trimmer with reversible double cutting edge blades.
- Hydraulic unit provides welding machine with compressing power.
- Low starting pressure ensures reliable welding quality of small pipes.
- Including the Temperature Controller and Timer, easy to know the time and temperature.
| Model | SDF450 |
| Welding range(mm) | 630 710 800 900 1000 1100 1200 |
| Welding Type | 0-90°ELBOW, Tee, Cross, 45°and 60° wyes(optional parts should be used) |
| Heating Plate Max. Temp. | 270°C |
| Temp.Deviation in Surface | ≤±7°C |
| Pressure Adjustable Ranges | 0-16MPa |
| Working Voltage | 380V50HZ |
| Heating Plate Power | 61.4KW |
| Planning Tool Power | 7.5KW |
| Hydraulic Unit Power | 7.5KW |
| Total Power | 76.4KW |
| Weight | 18000KG |
| Volume | 45.93M3 |
====>>Products that our machines can produce
====>>Packing And Delivery
====>>Exhibition
