| Overall Dimension(L*W*H) | 13000*3000*1800mm(Size can be chose freely) |
| Tare Weight | 10t |
| Loading Weight | 80t |
| Axle | 13T 3/4 pcs, BPW or FUWA or other china brand |
| Leaf Spring | 90*16-10 -6/8 sets, Funiu or Taiyue or other china brand |
| Suspension system | Mechanical Suspension / air suspension / single point suspension (Germany Type or America Type or Japan Type) |
| Main Beam | The height of the beam is 500 mm, upper plate 20 mm,down plate is 20 mm,middle plate is 12 mm, Material is Q 345B Steel |
| Cross member | 12#C type or AB type |
| Side rail | 250# "T" type |
| King pin | 3.5" |
| Platform | Q 235, checkered plate, 4 mm. |
| Hole / lashing | 12 pcs per side,24pcs in total |
| Hook | 9pcs per side,18pcs in total |
| Landing legs | 28 T total Lifting capacity and 50 T static capacity,two speeds |
| Brake system | Brand: Xinya Type: Dual line braking system Brake Air chamber: 6 in total, T30/30*4 + T30*2 Air tank: 40L*2 unit ABS: none |
| Electric system | 24V LED light waterproof wire; 7 ways (7 wire harness); Tail lamp with turn signal & brake light & side lamp & reflector etc. |
Features:
1. Different length available.
2. Gooseneck type: hydraulic gooseneck, detatchable gooseneck, radial gooseneck etc.
3. Axles can be 2,3 or 4 etc. Steering axle & hydraulic axle available.
3. Line lowbed available.
4. Platform extendable, super low platform availale.
5. Twist lock available.
6. Fence available.
XINYA have been in truck trailer field for more than 20 years.
Our products are famous in aftermarket.
We've export to Europe, South America, South Africa and Southeast Asia
We've passed ISO9001:2000 & BV & SGS & CCC certificates
We've set up unified technical departments and testing standards.
We've invested in trailer parts (axle, suspension, fifth wheel, kingpin, landing gear, twist lock etc) .
We've take part in international exhibitions.
Multiple production lines, able produce multiple types truck trailers and spare parts.
XINYA IS THE SOLE COATING FACTORY IN TRUCK TRAILER FIELD IN CHINA!!!
We keep good relations with main truck manufactrers in China. And we can supply all brands dump truck made in China. HOWO, SHACMAN, BEIBEN, DONGFENG, SINOTRUK, BEIBEN, FOTON, C&C, and so on. More details for these trucks, feel free to contact us please.
We can produce goods according to customers' requests or drawings;
Short delivery & Safe packing;
Small order quantity is acceptable;
More details for these trucks, feel free to contact us please.
