Model NO.
LT1304
Service Life
≤1 Year
Size
Small
Color
Red
Condition
New
Front Wheel Tread
1265 mm
Rear Wheel Tread
1200 mm
Min. Ground Clearance
330 mm
Rated Power
36.8 Kw
Max. Traction Force
11.7 Kn
Transport Package
Nude
Specification
3770x1620x2130
Trademark
Oriemac
Origin
China
Production Capacity
350units/Month
Type:
Wheel Tractor
Usage:
Farm Tractor, Garden Tractor, Lawn Tractor
Certification:
ISO, CE, EPA, CCC, ISO/TS16949, EEC, XQC
Drive Wheel:
4WD
Emission Standard:
Euro II
Fuel:
Gas / Diesel
Lutong Strong Power Agricultural Machine 130hp Tractor
Contact Person: Vicky Zhu
Product Description
Product Specifications
Product Show
Company Information
Contact Person: Vicky Zhu
Product Description
Main Features
Adopt diesel engine, good reliability, large reserves of torque, low fuel consumption, high economic efficiency;
Double-function clutch, operate independently, high transmission capacity, effective and reliable, comfortable operation;
Gearbox using 4 × (4+2) engaging sleeve, shuttle-type gearshift , there are 16 forward gears, 8reverse gears, reasonable match between the gears, and have high efficiency;
Independent power take off device, smooth transmission, large capacity;
Full hydraulic front wheels steering, independent oil circuit for steering system, manipulating flexible, reliable, and save energy;
Adopt hydrostatic disc-type brakes, a large braking torque, the braking effect is good;
Adopt high pressure type lifting device, reliable, easy maintenance, multi-hydraulic output can be optioned;
Final transmission adopts planetary gear mechanism, compact structure, large reduction ratio;
New streamlined appearance, generous, modern, fashion;
Product Specifications
| Tractor Model | LT1304 | |
| Drive Type | 4×4 | |
| Overall Dimension L×W×H(mm) | 5050×2370×3000 | |
| Wheel base(mm) | 2688.5 | |
| Front wheel tread(mm) | 1822-2153 | |
| Rear wheel tread(mm) | 1662-2262 | |
| Min. ground clearance(mm) | 470 | |
| Min. steering radius | 7 | |
| Min. operating weight (KG) | 4810 | |
| Gearbox gears number | 12/4 | |
| Speed | Forward(Kw/h) | 29.63-2.19 |
| Reverse(Kw/h) | 13.83-4.72 | |
| Engine | Model | LR6A3ZU22/0956E |
| Rated power (Kw) | 95.6 | |
| Type | 6 cylinders, in line, water cooling, 4 strokes, direct injection, natural aspiration | |
| Rated speed (r/min) | 2200 | |
| Tires spec. | Front tires | 14.9-26 |
| Rear tires | 18.4-38 | |
| Steering Type | ||
| Max. lifting force( KN ) | ≥28 | |
| Front / rear Ballast (KG) | 600/400 | |
| Control type of ploughing depth | Height control & flotation control | |
| PTO | Type | Rear-mounted, Independent type |
| Speed (r/min) | 540/720 | |
| Power(Kw) | 81.7 | |
| Max. traction force (KN) | 32 | |
