Model NO.
Luzhong-704B
Type
Wheel Tractor
Usage
Farm Tractor
Certification
ISO, CCC
Drive Wheel
4WD
Emission Standard
Euro II
Fuel
Gas / Diesel
Service Life
Over 10 Years
Size
Small
Color
Red
Condition
New
Gear Box
(4+1)X2 Composed Type
Gear Shifts
F8+R2
Engine
Vertical Type, 4 Cylinders
Steering
Hydraulic Power Steering
Clutch
Dual Stage, Dry Friction
Brake
Shoe Brake
Options
Air Brake, Hydraulic Outlet, Ballast
Cab
Optional
Function
Field Works, Transportation
Farm Implement
Trailer, Tiller, Plough, Harrow, Cultivator
Trademark
Luzhong
Transport Package
Either in Complete Set or in Steel Frame Packing
Specification
70HP
Origin
Weifang, China
HS Code
8701901190
The tractor can accomplish various farm works when attaching different farm implements, such as hole driling, plowing, rotary tilling, harrowing, seeding, harvesting, spraying, grass cutting and transportion as well, and also can be equipped with front end loader and back hoe.
Technical Data:
| Model | Luzhong-704B |
| Type | 4WD |
| Overall dimensions (mm) | 3570X1635X2160 |
| Wheel Base (mm) | 1880 |
| Front Tread (mm) | 980/1080/11801280 |
| Rear Tread (mm) | 1050--1300 |
| Min. Ground Clearance | 370 |
| Rated Drawbar pull (kN) | 10.3 |
| Starting Method | Electric Starting |
| No.of gears | 8F+2R |
| Engine Model | SD4DW3Z |
| Type | 4-stroke, vertical, 4 cylinders |
| Bore X Stroke (mm) | 93x102 |
| Rated power (kW) | 51.5 |
| Rated Speed (rpm) | 2400 |
| Cooling type | Water circulating cooling type |
| Steering type | Front wheel power steering |
| Braking system | Shoe brake |
| Clutch | dry, single plate, constant mesh |
| Transmission Box | (4+1)X2 composed |
| Front Tyre Size | 6.50-16/7.50-16 |
| Rear Tyre Size | 11.2-24/11.2-28 |
| Three Point Linkage Type | Catagory I, Rear mounted |
| PTO Type | Type I,rear mounted, Non-independent |
| PTO Rev. | 720, 760 or 540/1000 Optional |
Detailed photos:
About Luzhong
More Photos:
Packing and Delivery: Steel frame packing or complete set according to you requirement.
Our clients:
More Tractors:
Farm Implements:
Delivery Period: 25 to 35 days against receipt of the deposit depends on the quantity ordered.
Payment terms: by T/T or L/C.
FAQ:
Q: Why choose us?
A: 1. Strong parts machining capability ensures the accuracy of the parts;
2. Strict quality controll ensures each tractor in best quality;
3. Powerful technology team, supplying technical service and developing new products all the time;
Q: Warranty period?
A: : 365 days from the date of delivery.
Q: How about the replace parts?
A: We can supply all the parts of tractors ordered from us.
