CLW51201
30T
7000-8000mm
2240mm
Heavy Duty
Trailing Arm Type
Flatbed
3
Self-dumping
ABS Anti-lock Braking System
Steel
New
End Tipper Trailer or Side Tipper Trailer
25cbm, 30cbm 3 Axle Tipper Trailer
Q345b or High Tensile Steel 610 and 700
Square Shape or U-Shape
Red/Green/White/Yellow
Hyva Brand Cylinder
L1, Fuwa, BPW
2 Axle or 3 Axle
Heavy Duty Mechanism or Air Suspension
Jost Brand 50#, 90#
CLW
Nake and Waxed Before on Board
CCC and ISO9001
Hubei
8704230090
Product Description
Heavy Duty 3 Axle 25cbm Dump Trailer End Tipper Semi Trailer
| Heavy Duty 3 Axle 25cbm Dump Trailer End Tipper Semi Trailer | |||||
| Tare Weight | 10500 kgs | ||||
| Payload | 45000 kgs | ||||
| Overall Length | 8630 mm | ||||
| Overall Width | 2500 mm | ||||
| Dump body size | 7200mmx2300mmx1500mm | ||||
| Photo for reference, final produce can be made according to exact requirements | |||||
| DUMPER BODY | |||||
| Volume | 24 m3 | ||||
| Side Wall | 4mm thickness | ||||
| Front Wall and floor | 6mm thickness | ||||
| SPECIFICATION | |||||
| Chassis | Heavy duty and extra durability designed I beam; high tensile steel Q345B for chassis and 610 for dumper body. Top Flange 16mm,width 140mm; Middle Flange 10mm ; Bottom Flange 18mm,width 140mm. | ||||
| Axle | 3 axles | ||||
| BPW axle , 13 Ton | |||||
| Hydraulic System | One set of HYVA cylinder | ||||
| Suspension | German Design Mechanical suspension | ||||
| Leaf Spring | 13-piece leaf spring. | ||||
| King Pin | JOST brand 2" Bolt-in King Pin | ||||
| Landing Gear | JOST brand Two-speed, manual operating, heavy duty landing gear | ||||
| Wheel Rim | 9.0R22.5 wheel rim, 13 pieces | ||||
| Tyre | 12R22.5 tubeless tire with one spare tire, 13 pieces | ||||
| Spare Tire | One set of spare tire including a carrier | ||||
| Braking System | WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber; 40L air tanks | ||||
| Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint | ||||
| Accessories | One standard tool box, tarpaulin is optional | ||||
Features:
1, Made by high tensile strengh steel, Q345B, Q610, 700
2, heave duty loading capacity. Dump volume: 25M3-55M3.
3, square shape or U-shape design, nice appearance.
4, Hydraulic system: A set of HYVA Brand cylinder.
5, Factory directly selling, high quality and compective price.
The picture of U shape end tipper semi trailer that we do:
Container Loading pictures for Tri-axle U-shape tipper/dump semi trailers:
Our factory show:
Our main products:
1. Dump Truck / Tipper Truck/Side Tipper/End Tipper
2. Fire Fighting Truck / Fire Truck / Fire Vehicle / Fire Engine
3. Truck with crane / Truck mounted crane
4. LPG Tank Truck Trailer/Oil Tank Truck / Fuel Tanker Truck
5. Water truck / Water Tank Truck / Water Sprinkler Truck
6. Concrete Mixer Truck
7. Van truck / Insulated truck/ Refrigeration truck
8. Fecal suction truck / Sewage suction truck,
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck,
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truck,
12. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )
