JSXTCT16/168
Long Term Technical Support for Container Trailer
1 Year
GS, RoHS, CE, ISO9001
New
15-20m
14-16t
3
Four-Arm
Straight Arm
10000×2550×3950
18000
6000×2400×550
Flat Roof with Sleeper
Have
12.00r20 Type Steel Wire 10+1 Pieces
JSXT
10000× 2550× 3950
China
Product Description
1. Low operating costs. It also provides loading, transportation and unloading. The price of a 6X4 truck-mounted crane equipped with a 14-ton crane is much lower than the total price of a 6X4 truck + a 14-ton truck crane. If Taking into account the costs of later diesel, daily maintenance, hiring drivers, insurance, and handling procedures, the cost advantage of truck-mounted cranes becomes even more obvious.
2. Truck-mounted cranes are widely used and are not limited by time. Many places in big cities do not allow trucks to drive during the day, so goods can only be transported at night. The charge for night cranes is very high. In this case, the advantages of truck-mounted cranes are obvious.
3. Generally, truck-mounted cranes do not need to travel long distances. General business can be settled in cash, and the freight will not take too long. The labor intensity is less than that of ordinary trucks.
tire | 12.00R20 type steel wire 10+1 pieces, with spare tire |
Power take-off interface | Yes QH50 |
PTO | have |
Front/rear overhang (mm) | Front: 1525, Rear: 2500 |
departure angle | Front: 16, Rear: 9 |
suspension | Leaf spring 10/12 front and rear multi-leaf springs, four main leaves + four riding bolts |
leaf spring | First 10, last 12 |
Number of axles | 3 |
Wheelbase (mm) | 4575+1400 |
Wheelbase (mm) | 2070/1860/1860 |
Drive type | 6*4 |
engine | WP12.400E201 |
Emission Standards | Euro5 |
suspension | leaf spring |
driving style | Steering wheel type, left-hand drive |
brake | Drum type |
Braking System | Air cut-off brake |
Spare tire rack | have |
light | have |
Voltage | 24V |
tank | 400L aluminum alloy |
color | According to user requirements |
Crane type | Straight arm (four-section arm) |
Crane model | SQS350 |
Number of crane boom sections | 4 sections |
Maximum lifting weight | 14T |
Maximum working radius | 17.2 meters |
Maximum lifting height | 19.2 meters |
Rated lifting moment | 25t.m |
Amplitude angle range | 0-75 degrees |
Rotation angle | 360 degrees |
support span | 8.3 meters |
Recommended system traffic | 80-100L/min |
System rated pressure | 33Mpa |
Crane weight | 5300KG |
Q1. What's your MOQ?
One unit trailer or truck.
Q2. Can you satisfy my special requirement?
Definitely! We are direct manufacturer and we have strong producing capacity and R&D capacity!
Q3. How about your product quality?
High quality has always been our advantage.We all use high quality brand materials with 100% quality assurance.
Q4. How can I get the price of your vehicle?
You can contact with us through any of the following contact information. Our personalized service person will respond you within 24hours.
Q5. Is it available to print our own brand on the vehicle?
Totally acceptable as you wish.
