Dump trailer,Also known as Tipper trailer, its structure includes chassis, box, and lifting sys.
Work by PTO supply oil to the cylinder, lifting box till to design angle, cargo slide out, improve unloading efficiency.
Mainly used to load sand and stones, and the loading capacity are 40t, 60t, 80t.
Main Dimensions dump semi trailer | |
Dimension | 11280*2495*3970mm ( outside) 10500*2300*1700mm (work space ) size can be your choose |
Tare weight | About 15600KGS |
Total Volume(m3) | 37 m³ or less than 60tons |
Side wall thickness(mm) | 6mm Q235 steel |
Bottom plate thickness(mm) | 8mm /Q235 steel |
Lifting system | Full set of Hyva (FC214-5-07130) Hydraulic Lifting Cylinder (FC196 MODEL use for 9 m length trailer) |
Chassis | |
Main Beams | Height:500mm, upper plate is 16mm,middle is 8mm(double+three plate),down plate is 18mm,material is Q345B steel |
Axle | 3 axles, FUWA/HUAJING brand 16tons per axles |
Landing Gear | JOST (D200T)or CHINA BRAND 28T |
King Pin | JOST 2.00 or 3.5 inch bolt-in king pin |
Suspension | Mechanical suspension/ America type / |
Leaf Spring | 90(W)mm*13(Thickness)mm*10 Layer |
Pneumatic Braking System | WABCO RE 6 relay valve; Spring brake chamber; 2 pieces of 45L air tanks. |
Rim | 9.00-22.5/8.00-20/8.5-20 China Brand |
Tire | /12.00R22.5/315 80R22.5/11.00R20 /12.00R20 Brand can be Optional |
ABS | Optional |
Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint |
Accessories | One standard tool box |
Shipping Terms | By Bulk Cargo or roro, the trailer size can be design according to your special requirement , the tractor truck can be choose 6*4 model . |
FAQ
Q1,What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packagesbefore you pay the balance.
Q2,What's your minimum quality?
1 unit
Q3,How about your delivery time?
A: Generally, it will take about 20 to 30 days after receiving your advance payment. The specific delivery time
depends on the items and the quantity of your order.
Q4,What's the warranty?
A: Engine, transmission, axle guarantee one year (Any faulty caused by incorrect operation or man-made
factors is exclusive of guarantee.)
A: We provide technical support for our trucks and whole life parts supply
