Products specification:
*L6F load cells are available in the capacities 50kg to 2t.
*And the customized capacity is available by request.
*Alumium construction with parallel beam.
*Silicon adhesive sealed,surface anodized and anti-corrosion.
*Intergral structure and easy installation.
*Suitable for pricing scales, platform scales and other electronic weighing devices.
Features:
1. Capacity:50kg to 2t .
2. High accuracy.
3. Max. platform size:
50-200kg 600x600mm.
250-500kg 600x800mm.
750-2000kg 1200x1200mm
4. With OIML approval.
Specifications:
| Capacity | kg | 50/100/150/200/250/500/750/1000/2000 | ||
| Accuracy | C3D | C3 | C3G | |
| Approvals | OIML R60 C3 | |||
| Maximum number of verification intervals | n max | 2500 | 3000 | 4000 |
| Minimum load cell verification interval | v min | Emax/5000 | Emax/7000 | Emax/11000 |
| Combined error | (%FS) | ≤±0.030 | ≤±0.020 | ≤±0.015 |
| Creep | (%FS/30min) | ≤±0.020 | ≤±0.0167 | ≤±0.0125 |
| Temperature effect on sensitivity | (%FS/10ºC) | ≤±0.021 | ≤±0.0175 | ≤±0.0131 |
| Temperature effect on zero | (%FS/10ºC) | ≤±0.028 | ≤±0.020 | ≤±0.0127 |
| Output sensitivity | (mv/v) | 2.0±0.2 | ||
| Input resistance | (Ω) | 406±6 | ||
| Output resistance | (Ω) | 350±3 | ||
| Insulation resistance | (MΩ) | ≥5000(50VDC) | ||
| Zero balance | (%FS) | 2 | ||
| Temperature, compensated | (ºC) | -10~+40 | ||
| Temperature, operating | (ºC) | -35~+65 | ||
| Excitation, Recommended | (V) | 5~12(DC) | ||
| Excitation, Max | (V) | 18(DC) | ||
| Safe overload | (%FS) | 150 | ||
| Ultimate overload | (%FS) | 300 | ||
| Corner correction | 0.02% load value/100mm | |||
Outline Dimension mm(inch) :
| Capacity | H | H1 | L | W | W1 | M |
| 50~200kg,250kgSE | 75(2.95) | 50(1.97) | 156(6.14) | 44(1.73) | 24(0.94) | M12-7H Depth20(0.79) |
| 250~500kg,750kgSE | 95(3.74) | 70(2.76) | 146(5.75) | 60(2.36) | 36(1.42) | M12-7H Depth18(0.71) |
| 750~2000kg | 125(4.92) | 95(3.74) | 176(6.93) | 76(2.99) | 46(1.81) | M16-7H Depth29(1.14) |
