JK60-HS88-4004BFED-0.35M
Printing Equipment
Variable Speed
Two-Phase
HB-Hybrid
Driving
Electromechanical
ISO9001, RoHS, Ce
Jkong Motor
0.65ohm
4.0A
3.1 N.M
2.4m.H
NEMA24 Closed Loop Steppping Motors
88mm
Available
4
1000lines
JK
Inner Pack and Poly and Master Carton and Pallet
Frame Size: 60mm*60mm
Changzhou City, China
8501109990
Product Description
NEMA24 Closed Loop Steppping Motors
(NEMA24,2phase,Model:JK60HS88-4004BFED-0.35M)
General Specifications:
Step Angle----------------------------1.8°±5%
Temperature Rise-------------------80ºC Max.
Insulation Resistant-----------------100MΩ Min.,500VDC
Dielectric Strength-------------------500VAC for one minute
Ambient Temperature ---------- -20ºC~+50ºC
Shaft Radial Play---------------------0.02Max.(450 g-load)
Shaft Axial Play-----------------------0.08Max.(450 g-load)
Motor Electrical Parameters:
Recommand JK-HSD60 NEMA24 Closed Loop Steppping Motors Driver(easy servo driver):
Standard wire length for encoder is 3 meters.
( Wire length can be customized:2m,3m,5m)
Any special request can be made according to the customer requirement.
Motor Dimension (unit=mm):
Features:
NEMA24 Closed Loop Steppping Motors Features:
1.Stepper motor closed loop system, never lose step.
2. Higher output torque and working speed than normal stepper motor.
3. Automatic current adjustment based on load, lower temperature rising.
4.Suitable for all mechanical load conditions (include low rigidity belt pulley and wheel), no need to adjust gain parameter.
5.Motor work smoothly and low vibration, high dynamic performance at acceleration and deceleration.
6. No vibration from high speed to zero speed.
7. 1000 encoder lines.
Applications:
Our NEMA24 Closed Loop Steppping Motors are widely used in these areas:
:
About Us JKong Motor:
We are a professional manufacturer for Stepper motor , Stepper driver, BLDC motor and DC motor. we can supply OEM service.
Our products all with CE and ROHS.
Welcome you visit our company Changzhou Jingkong Motor&Electric Appliance Co.,Ltd
Certifications:
FAQ:
Q1: What about your warranty?
A: We guarantee is one year . for sea order . is 15months.
Q2: Do you have any certificates?
A: Yes, we have. All the motors have been approved by CE and Rohs.
Q3: Do you offer OEM AND ODM service?
A: Yes. We can supply OEM andmake customized design for any specific application.
Q4: How can be your brand distributor?
A: We will check your capacity and help you promote and expand the market.
Q5: What's the delivery time ?
A: Except special order. For samples usually 10-14 working days . for batch order . usually 20-25days.
(NEMA24,2phase,Model:JK60HS88-4004BFED-0.35M)
General Specifications:
Step Angle----------------------------1.8°±5%
Temperature Rise-------------------80ºC Max.
Insulation Resistant-----------------100MΩ Min.,500VDC
Dielectric Strength-------------------500VAC for one minute
Ambient Temperature ---------- -20ºC~+50ºC
Shaft Radial Play---------------------0.02Max.(450 g-load)
Shaft Axial Play-----------------------0.08Max.(450 g-load)
Motor Electrical Parameters:
| Model No. | Step Angle | Motor Length | Current /Phase | Resistance /Phase | Inductance /Phase | Holding Torque | Lead wires | Rotor Inertia | Motor Weight |
| ( °) | (L) mm | A | Ω | mH | N.m | No. | g.cm2 | Kg | |
| JK60HS88-4004BFED-0.35M | 1.8 | 88 | 4.0 | 0.65 | 2.4 | 3.1 | 4 | 840 | 1.4 |
| JK60HS100-4004BFED-0.35M | 1.8 | 100 | 4.0 | 0.7 | 3.0 | 4.0 | 4 | 980 | 2.0 |
Recommand JK-HSD60 NEMA24 Closed Loop Steppping Motors Driver(easy servo driver):
Standard wire length for encoder is 3 meters.
( Wire length can be customized:2m,3m,5m)
Any special request can be made according to the customer requirement.
Motor Dimension (unit=mm):
Features:
NEMA24 Closed Loop Steppping Motors Features:
1.Stepper motor closed loop system, never lose step.
2. Higher output torque and working speed than normal stepper motor.
3. Automatic current adjustment based on load, lower temperature rising.
4.Suitable for all mechanical load conditions (include low rigidity belt pulley and wheel), no need to adjust gain parameter.
5.Motor work smoothly and low vibration, high dynamic performance at acceleration and deceleration.
6. No vibration from high speed to zero speed.
7. 1000 encoder lines.
Applications:
Our NEMA24 Closed Loop Steppping Motors are widely used in these areas:
| a.nc machine tool |
| b.medical instruments |
| c.Textile machinery |
| d.packaging machinery |
| e.printing equipment(3D printer) |
| f.music fountain |
| g.security surveillance |
| h.other industrial automatic equipment |
:
About Us JKong Motor:
We are a professional manufacturer for Stepper motor , Stepper driver, BLDC motor and DC motor. we can supply OEM service.
Our products all with CE and ROHS.
Welcome you visit our company Changzhou Jingkong Motor&Electric Appliance Co.,Ltd
Certifications:
FAQ:
Q1: What about your warranty?
A: We guarantee is one year . for sea order . is 15months.
Q2: Do you have any certificates?
A: Yes, we have. All the motors have been approved by CE and Rohs.
Q3: Do you offer OEM AND ODM service?
A: Yes. We can supply OEM andmake customized design for any specific application.
Q4: How can be your brand distributor?
A: We will check your capacity and help you promote and expand the market.
Q5: What's the delivery time ?
A: Except special order. For samples usually 10-14 working days . for batch order . usually 20-25days.
Any question or inquiry of our product NEMA24 Closed Loop Steppping Motors , 3.1N.m,torque4.0N.m are available,welcome to contact us!
