YG-S200
Video Guidence
2 Years
CE, ISO 9001:2000, ISO 9001:2008
New
DC Motor
75-325mm
100-200
Optional
Rotary
Drilling Rig Coring Exploration Machine
100m 200m 400m 800m 1000m 1500m
Crawler Type Full Hydraulic
Wireline Coring Drilling Rig
Double Tube Coring Drill Rig
Ntw, Btw, Htw, Ptw
Nq, Bq, Hq, Pq
1.5m, 2m, 3m
Fast Speed Coring Drilling
Drilling Sample
10-20 Working Days
High Quality, Good Customers Feedback
Diamond Core Drilling Rig
Core Drilling Machine
Core Drilling Rig Machine
YUGONG
Wooden Box, Container.
Spidle, winch, drill mast, mud pump.
Henan, China
8430419000
Product Description
Portable Full Hydraulic Crawler Rotary Mine Diamond Wireline Mining Exploration Borehole Core Drilling Rig for Soil Geotechnical Investigation
| Parameter table of multifunctional water well core drilling rig | |||||
| Model(NEW) | YG300D | YG400D | YG600D | YG800D | YG1000D |
| Max. Drilling depth | 300m | 400m | 600m | 800m | 1000m |
| Drilling diameter | 55-168mm | 55-168mm | 55-168mm | 55-168mm | 55-168mm |
| Core diameter | 48-150mm | 48-150mm | 48-150mm | 48-150mm | 48-150m |
| Drill pipe length | 2M | 2M | 2M | 2M | 2M |
| Drilling angle | 45-90° | 45-90° | 45-90° | 45-90° | 45-90° |
| Diesel engine power | 78KW | 91KW | 92KW | 92KW six-cylinder | 132KW |
| Power head speed | 100-1100rpm | 100-1100rpm | 100-1100rpm | 100-1300rpm | 100-1500rpm |
| power head torque | 280-2100N.m | 280-2100N.m | 280-2400N.m | 280-2800N.m | 280-35000N.m |
| Total Weight | 3.6t | 4.1t | 5.5t | 7.5t | 9t |
| Dimensions | 3.6m*1.3m*1.7m | 3.6m*1.5m*1.8m | 3.6m*1.8m*2.1m | 3.8m*2m*2.5m | 4.2m*2m*2.3m |
| 1.Centralized Console |
| The control functions are concentrated on the console, which facilitates operation and saves time and effort |
| 2.Crawler Chassis |
| Equipped with a wireless remote control crawler chassis, it is suitable for a variety of terrains and can control the drilling rig's movement with ina safe distance |
| 3.Compact And Reasonable Body |
| The whole machine is reasonably designed,flexible and durable. |
| 4.Hydraulic Power Head |
| Prevent accidental detachment of the rod and provide strong propulsion force |
Our Services1.We have more than15 years manufacture and export experience.
2.Exporting to all over the world,win high reputation among customers.
3.CE, ISO 9001 and Strict Production Guideline to guarantee the high quality of our products.
4.Near the Qingdao port convenient for exporting.
5.Customer service staff 24 hours online,offer free technical support.
6.Factory and Competitive Price we offer.
7.Strong Research & Development technical team.
8.Various machinery to meet all your needs at our factory.
9.Engineers are available to guide the installation and take care of other problems.
10.We offer OEM&ODM service to meet all your requirements.
