MQH37A/MQH37/MQG37
/
12 Months
CE, ISO9001
New
>40m
37t
3
Five-Arm
Folding
/
Nude Packing
14100*2500*4000mm
Jiangsu, China
84305090
Product Description
37Ton MQH37A 20ft 40ft Container Side Lifter Container Sidelifter with semitrailer
Products Description
Side loader MQH37A have several advanced core technologies and a number of patents,it can transfer containers to other trailers,
trucks, or on to the ground. Its characters including big lifting capacity, large working range, wide application range, good
versatility and strong guarantee ability, meet the demands of lifting container anywhere. It is widely for shipping, port,
railway, storage and custom etc.Its characteristics of "rapid, vivid, efficiency, convenience" get more and more understanding and
approbations.
Advantages and highlights:
* Power take off(PTO) or diesel APU;
* Sideloader can slide to fit 20ft-40ft containers.
* Wireless remote contrcl/ manual operating.
* Engine throttle size and engine speed can be control, improving working efficiency.
* The front and rear crane can work together and separate, adjusting container conveniently.
* Safety control with stop button.
* Elegant appearance, reliable performance,
* Convenient operation, facilitate manufanture and maintenance.
trucks, or on to the ground. Its characters including big lifting capacity, large working range, wide application range, good
versatility and strong guarantee ability, meet the demands of lifting container anywhere. It is widely for shipping, port,
railway, storage and custom etc.Its characteristics of "rapid, vivid, efficiency, convenience" get more and more understanding and
approbations.
Advantages and highlights:
* Power take off(PTO) or diesel APU;
* Sideloader can slide to fit 20ft-40ft containers.
* Wireless remote contrcl/ manual operating.
* Engine throttle size and engine speed can be control, improving working efficiency.
* The front and rear crane can work together and separate, adjusting container conveniently.
* Safety control with stop button.
* Elegant appearance, reliable performance,
* Convenient operation, facilitate manufanture and maintenance.
Product Parameters
Item | Item | Unit | Parameters |
Lifting Performance | Max. lifting capacity | kg | 37000 |
Max. working range | mm | 4000 | |
Max. stabilizer outreach | mm | 3200 | |
Weight | Curb mass | kg | 14500 |
Mass of sidelifter | kg | 7250 | |
Maximum gross mass | kg | 40000 | |
Dimension | Outline dimension of semi-trailer(L×W×H) | mm | 14100×2500×4000 |
Outline dimension of sidelifter(L×W×H) | mm | 1020×2500×2490 | |
Wheel base | mm | 8000+1350+1350 | |
Track(front axle/rear axle) | mm | 1820/1820/1820 | |
Front overhang / Rear overhang | mm | -/2370 | |
Approach angle/Departure angle | ° | -/13 | |
(Option) Engine | Model | -- | Ku-bota V2403-M-DI-E3B-CSL-1 |
Power/rotation speed | kW/r/min | 36.5/2600 | |
Emission standard | -- | Off-road, Euro III |
