1. Product name :CZF Series Marine small sized Axial Exhaust Fan
2 Total Pressure:120~935MPa
3.Power:0.28-30KW
4.Flow Rate:900-114000m3/H
5.Certificate: ABS, KR, CCS, LR, DNV▪GL, BV, CE, NK
The CZF Axial Exhaust Fan is a type of ventilation fan that is designed to exhaust air from a specific area, such as a room or building. This fan is commonly used in industrial settings, such as factories, warehouses, and workshops, where there is a need to remove stale or contaminated air and replace it with fresh air.
The CZF Axial Exhaust Fan operates by drawing air in through its blades and then expelling it out through the rear of the fan. This creates a flow of air that can help to improve air quality and reduce the risk of respiratory problems and other health issues associated with poor air circulation.
Some of the key features of the CZF Axial Exhaust Fan include its high efficiency, low noise levels, and durable construction. It is also easy to install and can be used in a variety of settings, including both indoor and outdoor applications.
Overall, the CZF Axial Exhaust Fan is a reliable and effective solution for improving air quality and ventilation in a wide range of industrial and commercial settings.
model | flow rate pa m3/h | static pressure pa (mmH2O) | static pressure pa (mH2O) | speed r/min | molor | kg weight | ||
hz freq | hz power | model | ||||||
| CZF-30A | 960 1200 1500 1740 1980 | 330(34) 310(32) 270(28) 230(24) 180(19) | 320(33) 295(31) 250(26) 200(21) 140(15) | 2920 | 50 | 0.25 | Y632-2-H | 50 |
| 1200 1500 1800 2100 2400 | 490(50) 440(45) 380(39) 310(32) 240(25) | 470(48) 420(43) 350(36) 270(28) 180(19) | 3500 | 60 | 0.56 | Y711-2-H | ||
| CZA-35A | 900 960 1080 1140 1200 | 160(17) 150(16) 130(14) 121(13) 110(12) | 150(16) 140(15) 125(13) 115(12) 105(11) | 1460 | 50 | 0.25 | Y711-4-H | 60 |
| 900 1200 1500 1800 | 250(26) 210(22) 160(17) 120(13) | 240(25) 200(21) 150(16) 100(11) | 1750 | 60 | 0.25 | Y711-4-H | ||
| CZF-35B | 1500 1800 2100 2400 2700 | 480(49) 420(43) 390(40) 330(34) 290(30) | 470(48) 400(41) 370(38) 300(31) 250(26) | 2920 | 50 | 0.55 | Y711-2-H | 70 |
| 1800 2100 2400 3000 3600 | 700(71) 640(65) 590(60) 460(47) 320(33) | 680(69) 620(63) 560(57) 410(42) 250(26) | 3500 | 60 | 0.75 | Y801-2-H | ||
| CZF-40A | 2160 2400 2700 3000 | 180(19) 160(17) 150(16) 140(15) | 160(17) 145(15) 130(14) 110(12) | 1460 | 50 | 0.55 | Y801-4-H | 65 |
| 2400 2700 3000 3300 3600 3900 | 270(28) 240(25) 230(24) 200(21) 180(19) 165(17) | 250(26) 220(23) 200(21) 170(18) 140(15) 120(13) | 1750 | 60 | 0.55 | Y801-4-H | 85 | |
| CZF-40B | 2500 3000 3300 3600 4200 | 490(50) 430(44) 400(41) 370(38) 300(31) | 450(46) 400(41) 370(38) 330(34) 250(26) | 2920 | 50 | 0.75 | Y801-2-H | 85 |
| 3000 3600 4200 4800 5100 | 710(72) 640(65) 550(56) 470(48) 410(42) | 680(69) 600(61) 500(51) 400(41) 330(34) | 3500 | 60 | 1.5 | Y90s-2-H | ||
| CZF-45A | 1680 1800 2100 2400 3000 | 235(24) 225(23) 200(21) 175(18) 125(13) | 230(24) 220(23) 190(20) 165(17) 110(12) | 1460 | 50 | 0.55 | Y801-4-H | 75 |
| 1920 2100 2400 2700 3000 3600 | 350(36) 340(35) 310(32) 285(29) 245(25) 185(19) | 340(35) 330(34) 300(31) 270(28) 230(24) 160(17) | 1750 | 60 | 0.55 | Y801-4-H | ||
| CZF-45B | 1980 2400 3000 3600 4200 | 250(26) 240(25) 220(23) 195(20) 150(16) | 240(25) 230(24) 205(21) 170(18) 120(13) | 1460 | 50 | 0.55 | Y801-4-H | 95 |
| 2400 3000 3600 4200 4800 | 360(37) 335(34) 315(32) 280(29) 240(25) | 350(36) 320(33) 290(30) 250(26) 200(21) | 1750 | 60 | 0.75 | Y802-4-H | ||
| CZF-50A | 3480 3900 4200 4800 5400 | 235(24) 220(23) 205(21) 190(20) 160(17) | 220(23) 200(21) 185(19) 160(17) 125(13) | 1460 | 50 | 0.55 | Y801-4-H | 100 |
| 4200 4800 5400 6000 6600 | 340(35) 320(33) 295(30) 265(27) 230(24) | 320(33) 290(30) 260(27) 220(23) 180(19) | 1750 | 60 | 0.55 | Y801-4-H | ||
| CZF-55A | 3900 4800 5400 6000 6600 7200 | 330(34) 310(32) 295(30) 270(28) 245(25) 215(22) | 320(33) 290(30) 270(28) 240(25) 210(22) 170(18) | 1460 | 50 | 1.5 | Y90L-4-H | 110 |
| 4800 6000 7200 8400 9000 9600 | 500(51) 450(46) 385(39) 330(34) 290(30) 255(26) | 480(49) 420(43) 340(35) 270(28) 220(23) 180(19) | 1750 | 60 | 2.2 | Y100L1-4-H | ||
| CZF-55B | 6600 7200 7800 8400 9000 9600 | 285(29) 280(29) 265(27) 255(26) 240(25) 230(24) | 250(26) 235(24) 215(22) 195(20) 175(18) 155(16) | 1460 | 50 | 1.5 | Y90L1-4-H | |
| 7200 9000 9600 10800 12000 13200 | 425(43) 390(40) 375(38) 345(35) 320(33) 285(29) | 380(39) 320(33) 300(31) 250(26) 200(21) 140(15) | 1750 | 60 | 2.2 | Y100L1-4-H | ||
| CZF-60A | 6600 7800 9000 10200 11400 | 345(35) 325(33) 290(30) 250(26) 200(21) | 320(33) 290(30) 240(25) 190(20) 125(13) | 1460 | 50 | 1.5 | Y90L-4-H | 125 |
| 8400 9600 10800 12000 13200 15000 | 490(50) 475(48) 440(45) 375(38) 310(32) 270(28) | 450(46) 420(43) 370(38) 290(30) 210(22) 140(15) | 1750 | 60 | 2.2 | Y100L1-4-H | ||
| CZF-70A | 4800 6000 7200 8400 9600 10200 | 530(54) 525(53) 515(52) 450(46) 370(38) 335(34) | 520(53) 515(52) 500(51) 430(44) 340(35) 300(31) | 1460 | 50 | 2.2 | Y100L1-4-H | 160 |
| 6000 8400 9600 10800 12000 13200 | 790(80) 740(75) 680(69) 605(61) 505(51) 405(41) | 780(79) 720(72) 650(66) 570(58) 460(47) 350(36) | 1750 | 60 | 4 | Y112M-4-H | ||
| CZF-70B | 10200 12000 13200 14400 15600 16800 | 415(42) 345(35) 355(36) 325(33) 295(30) 270(28) | 380(39) 330(34) 300(31) 260(27) 220(23) 180(19) | 1460 | 50 | 2.2 | Y100L1-4-H | |
| 12000 13800 15000 16800 18600 20400 | 595(60) 560(57) 520(53) 490(50) 430(44) 360(37) | 550(56) 500(51) 450(46) 400(41) 320(33) 230(24) | 1750 | 60 | 5.5 | Y132S-4-H | ||
| CZF-75A | 12000 13200 14400 15600 16800 | 215(22) 205(21) 200(21) 190(20) 180(19) | 180(19) 165(17) 150(16) 130(14) 110(12) | 970 | 50 | 1.5 | Y100L-6-H | 205 |
| 14400 15600 16800 18000 19200 24000 | 320(33) 310(32) 300(31) 280(29) 270(28) 290(30) | 270(28) 250(26) 230(24) 200(21) 180(19) 150(16) | 1160 | 60 | 2.2 | Y112M-6-H | ||
| CZF-75B | 9600 12000 14400 16800 19200 16200 | 460(47) 455(46) 420(43) 400(41) 340(35) 220(23) | 440(45) 420(43) 380(39) 330(34) 250(26) 160(17) | 1460 | 50 | 4 | Y112M-4-H | 235 |
| 12000 13800 16800 18000 19200 24000 | 655(66) 645(65) 620(63) 600(61) 590(60) 490(50) | 620(63)600(61) 550(56) 520(53) 500(51) 350(36) | 1750 | 60 | 5.5 | Y132S-4-H | ||
| CZF-75C | 12600 15000 18000 21000 22200 | 490(50) 480(49) 450(46) 395(40) 370(38) | 450(46) 425(43) 370(38) 290(30) 250(26) | 1460 | 50 | 5.5 | Y132S-4-H | |
| 15600 18000 21000 24000 25500 | 680(49) 675(68) 635(64) 590(60) 555(56) | 620(63) 600(61) 530(54) 450(46) 400(41) | 1750 | 60 | 7.5 | Y132M-4-H | ||
| CZF-90A | 18600 21000 22800 24000 25500 27000 | 330(34) 300(31) 280(29) 260(27) 240(25) 225(23) | 290(30) 250(26) 220(23) 195(20) 165(17) 130(14) | 970 | 50 | 4.0 | Y132M1-6-H | 300 |
| 21000 24000 27000 30000 33000 | 500(51) 480(49) 415(42) 345(35) 278(28) | 450(46) 410(42) 330(34) 240(25) 150(16) | 1160 | 60 | 5.5 | Y132M2-4-H | ||
| CZF-90B | 21000 24000 27000 28800 30000 | 390(40) 370(38) 335(34) 305(31) 275(28) | 340(35) 300(31) 250(26) 210(22) 170(18) | 970 | 60 | 5.5 | Y132M-6-H | |
| 25200 27000 30000 33000 36000 | 555(56) 475(48) 505(51) 465(47) 398(40) | 480(49) 440(45) 400(41) 340(35) 250(26) | 1160 | 50 | 7.5 | Y160M-4-H | ||
| CZF-90C | 10200 12000 15000 18000 21000 | 390(40) 370(38) 335(34) 305(31) 350(36) | 650(66) 620(63) 550(56) 450(46) 300(31) | 970 | 50 | 5.5 | Y132M-6-H | |
| 12000 15000 18000 21000 24000 | 970(98) 910(92) 840(85) 730(74) 600(61) | 950(96) 880(89) 800(81) 680(690 530(54) | 1460 | 60 | 7.5 | Y132M-4-H | ||
| CZF-90D | 17400 21000 24000 27000 31200 | 655(66) 600(61) 560(57) 490(50) 410(42) | 620(63) 550(56) 495(50) 405(41) 300(31) | 1460 | 60 | 7.5 | Y132M-4-H | |
| CZF-90D | 21000 24000 27000 30000 33000 36000 | 910(92) 895(90) 833(84) 775(78) 675(68) 600(61) | 860(87) 830(84) 750(76) 670(68) 550(56) 450(46) | 970 | 50 | 11 | Y160M-4-H | |
| CZF-95A | 25500 30000 33000 36000 39000 42000 | 710(72) 685(69) 670(68) 640(65) 590(60) 525(53) | 650(66) 600(61) 570(58) 520(53) 450(46) 360(37) | 1460 | 50 | 11 | Y160M-4-H | 450 |
| 30000 33000 36000 39000 42000 48000 | 1035(104) 100(102) 100(102) 970(99) 925(94) 795(81) | 950(96) 900(91) 880(89) 830(84) 760(77) 580(59) | 1750 | 60 | 18.5 | Y180M-4-H | ||
| CZF-100A | 25800 30000 33000 36000 39000 | 330(34) 310(32) 290(30) 270(28) 245(25) | 280(29) 240(25) 210(22) 175(18) 130(14) | 970 | 50 | 5.5 | Y132M-6-H | 450 |
| 30000 33000 36000 39000 42000 48000 | 490(50) 470(48) 460(47) 435(44) 405(41) 325(33) | 420(43) 390(40) 360(37) 320(33) 270(28) 150(16) | 160 | 60 | 7.5 | Y160M-6-H | ||
| CZF-100B | 30000 33000 36000 39000 42000 45000 | 440(45) 420(43) 400(41) 375(38) 345(35) 280(29) | 370(38) 340(35) 300(31) 260(27) 210(22) 130(14) | 970 | 50 | 7.5 | Y160M-6-H | 420 |
| 36000 39000 42000 48000 54000 | 630(64) 615(62) 585(60) 495(51) 430(44) | 540(54) 500(51) 450(46) 320(33) 210(22) | 1160 | 60 | 11 | Y160L-6-H | ||
| CZF-110A | 36000 39000 42000 45000 48000 51000 | 730(38) 355(36) 330(34) 315(32) 290(30) 275(28) | 300(31) 275(28) 240(25) 210(22) 170(18) 140(150 | 970 | 50 | 7.5 | Y160M-6-H | 500 |
| 42000 18000 54000 6000 63000 | 540(55) 520(53) 470(48) 385(39) 365(37) | 450(46) 400(41) 320(33) 200(21) 167(17) | 1160 | 60 | 11 | Y160L-6-H | ||
| CZF-120A | 48000 51000 54000 57000 60000 63000 | 335(34) 385(39) 365(37) 350(36) 320(33) 305(31) | 350(36) 290(30) 260(27) 230(24) 190(20) 160(17) | 970 | 50 | 11 | Y160L-6-H | 660 |
| 51000 54000 60000 66000 72000 78000 | 615(63) 605(61) 550(56) 500(51) 440(45) 380(39) | 520(53) 500(50) 420(43) 340(35) 250(26) 160(17) | 1160 | 60 | 15 | Y180L-6-H | ||
| CZF-140A | 48000 54000 60000 66000 72000 | 405(41) 380(39) 350(36) 305(31) 260(27) | 360(37) 320(33) 280(29) 220(23) 160(17) | 970 | 50 | 11 | Y160L-6-H | 830 |
| 54000 60000 66000 72000 78000 84000 | 580(59) 560(57) 545(56) 490(50) 430(44) 390(40) | 520(53) 490(50) 460(47) 390(40) 310(32) 250(26) | 1160 | 60 | 15 | Y180L-6-H | 830 | |
| CZF-140B | 45000 54000 60000 66000 72000 78000 | 470(48) 450(46) 410(42) 375(38) 310(32) 270(28) | 430(44) 390(40) 340(35) 290(30) 210(22) 150(16) | 970 | 50 | 11 | Y160L-6-H | 830 |
| 54000 60000 72000 84000 90000 | 680(69) 660(67) 600(61) 480(49) 420(43) | 620(63) 590(60) 500(51) 340(35) 260(270 | 1160 | 60 | 18.5 | Y200L2-6-H | 850 | |
| CZF-140C | 48000 54000 60000 66000 72000 78000 | 525(53) 510(52) 490(50) 465(47) 420(43) 370(38) | 480(49) 450(46) 420(43) 380(39) 320(33) 250(26) | 970 | 50 | 15 | Y180L-6-H | 830 |
| 54000 60000 72000 84000 96000 108000 | 780(79) 700(71) 710(72) 640(65) 530(54) 425(43) | 720(73) 700(71) 610(62) 500(51) 350(36) 170(18) | 1160 | 60 | 22 | Y200L2-6-H | 850 | |
| CZF-140D | 54000 60000 66000 72000 78000 84000 90000 | 650(66) 640(65) 605(62) 570(58) 530(54) 490(50) 440(45) | 590(60) 570(58) 520(53) 470(48) 410(42) 350(36) 280(29) | 970 | 50 | 18.5 | Y200L1-6-H | |
| 66000 78000 90000 102000 108000 114000 | 935(95) 890(90) 820(83) 685(70) 630(64) 595(60) | 850(86) 770(78) 660(67) 480(49) 400(41) 340(35) | 1160 | 60 | 30 | Y200M-6-H | 950 | |
The CZF Axial Exhaust Fan is a type of ventilation fan commonly used in various industrial and commercial applications. Some of the key features of this fan include:
1. High Efficiency: The CZF Axial Exhaust Fan is designed to provide high efficiency ventilation by moving large volumes of air with minimal power consumption.
2. Durable Construction: This fan is built with high-quality materials, such as a galvanized steel frame, aluminum alloy blades, and a powder-coated finish, ensuring long-lasting durability and resistance to corrosion.
3. Low Noise Level: The fan operates at a low noise level, making it suitable for use in noise-sensitive environments.
4. Easy Maintenance: The fan is designed for easy maintenance, with a detachable fan blade for convenient cleaning and a belt-driven system for simple belt replacement.
5. Energy Efficient: The CZF Axial Exhaust Fan is engineered for maximum energy efficiency, reducing operational costs and promoting sustainability.
6. Customizable Options: The fan is available in a range of sizes, speeds, and mounting options, making it customizable to fit specific ventilation needs.
Overall, the CZF Axial Exhaust Fan is a reliable and effective ventilation solution for a variety of applications.
