SCC750A-8
Video Online Service
57m
75t
ISO9001, CE, RoHS
New
1year
75t
57m
316 T.M
135m/Min
top brand
Nude Package
8t
China
Product Description
Hoisting Machine 75t Crawler Crane SCC750A-8
- Adaptable, efficient and flexible
With the standard graded load table, the trestle construction adaptability is strong;
Standard extended arm iron pulley, strong wear resistance;
Standard track frame middle support sprocket, long distance driving more wear-resistant;
Optional free drop hook, multi-functional application more widely. - Easy to operate, low cost
The lower arm of the main belt is 3M transport, efficient disassembly and low transfer cost;
Universal design of boom, counterweight and hook, low procurement and operating costs;
The key parts are common with the car crane and the excavator, and the maintenance premium is low. - Intelligent high, save worry and effort
Fault self-diagnosis, faster processing;
Rotary multi-mode to meet the needs of different personnel and working conditions;
Voice-assisted, intelligent and efficient. Item Unit SCC750A-8 SCC1000A-9 SCC2200A-8 Max. rated lifting weight
t 75 100 220 Max. main arm length
m 57 57 85 Max. lifting moment
t·m 316 412 1304 Max. single rope speed
m/min 135 135 130 Max. turning speed
r/min 2.5 2.4 1.3 Max. travel speed km/h 1.1 1.6 1 Rear counterweight weight t 23.5
32 79 Max. counterweight t - 32+7.8 79+25 Ground specific voltage Mpa 0.076 0.085 0.118 Engine type - Weichai Yuchai Weichai Max. power kW/rpm 221/2200 191/2200 247/2000 Max. torque N·m/rpm 1200/1600 1080/1600 1600/1400
